9GPC | pdb_00009gpc

The crystal structure of ManDH5 E303Q mutant at 1.4 Angstroms Resolution - a beta-D-Mannanase of GH5 family from Dictyoglomus thermophilium

• PDB DOI: https://doi.org/10.2210/pdb9GPC/pdb

• Classification: HYDROLASE
• Organism(s): Dictyoglomus thermophilum
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2024-09-07 Released: 2025-09-17
• Deposition Author(s): Sivron, Y., Romano, A., Shoham, Y., Shoham, G.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:
  0.169 (Depositor), 0.172 (DCC)
• R-Value Work:
  0.147 (Depositor), 0.152 (DCC)
• R-Value Observed:
  0.148 (Depositor)

Starting Model: experimental

Literature

The crystal structure of ManDH5 E303Q mutant at 1.4 Angstroms Resolution - a beta-D-Mannanase of GH5 family from Dictyoglomus thermophilium

Sivron, Y., Romano, A., Shoham, Y., Shoham, G.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 67.5 kDa
• Atom Count: 5,241
• Modeled Residue Count: 563
• Deposited Residue Count: 568
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DUF5060 domain-containing protein	A	568	Dictyoglomus thermophilum	Mutation(s): 1  Gene Names: ENW00_02810
UniProt
Find proteins for A0A7C3MIF0 (Dictyoglomus thermophilum) Explore A0A7C3MIF0  Go to UniProtKB:  A0A7C3MIF0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	B [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:  0.169 (Depositor), 0.172 (DCC)
• R-Value Work:  0.147 (Depositor), 0.152 (DCC)
• R-Value Observed: 0.148 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 95.499	α = 90
b = 99.128	β = 90
c = 154.563	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
PHENIX	refinement
xia2	data scaling
Coot	model building
PHASER	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2025-09-17
Deposition Author(s): Sivron, Y., Romano, A., Shoham, Y., Shoham, G.

Revision History

• Version 1.0: 2025-09-17
  Type: Initial release
