9GHT | pdb_00009ght

Crystal Structure of EGFR-WT in Complex with BI-4020

• PDB DOI: https://doi.org/10.2210/pdb9GHT/pdb

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Spodoptera frugiperda
• Mutation(s): No


• Deposited: 2024-08-16 Released: 2026-03-04
• Deposition Author(s): Niggenaber, J., Mueller, M.P., Rauh, D.
• Funding Organization(s): German Federal Ministry for Education and Research, European Regional Development Fund, Other private, Other government

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:
  0.237 (Depositor), 0.234 (DCC)
• R-Value Work:
  0.198 (Depositor), 0.197 (DCC)
• R-Value Observed:
  0.200 (Depositor)

Starting Model: experimental

Literature

Selective Targeting of EGFR-Exon20 Insertion Mutations in Non-Small Cell Lung Cancer with Nazartinib and BI-4020 Inspired Hybrid Inhibitors

Grabe, T., Jeyakumar, K., Niggenaber, J., Grabe, B., Koska, S., Zischinsky, M., Unger, A., Weisner, J., Arndt, A., Mueller, M.P., Rauh, D.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 38.42 kDa
• Atom Count: 2,387
• Modeled Residue Count: 300
• Deposited Residue Count: 333
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Epidermal growth factor receptor	A	333	Homo sapiens	Mutation(s): 0  Gene Names: EGFR, ERBB, ERBB1, HER1 EC: 2.7.10.1
UniProt & NIH Common Fund Data Resources
Find proteins for P00533 (Homo sapiens) Explore P00533  Go to UniProtKB:  P00533
PHAROS:  P00533 GTEx:  ENSG00000146648

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
XA4 (Subject of Investigation/LOI)	B [auth A]	(20R)-10,15,20-trimethyl-2-[(4-methylpiperazin-1-yl)methyl]-18,19,20,21-tetrahydro-15H,17H-12,8-(metheno)pyrazolo[3',4':2,3][1,5,10,12]oxatriazacycloheptadecino[12,11-a]benzimidazol-7(6H)-one C30 H38 N8 O2 AIQBYZOTCIQTGW-HXUWFJFHSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:  0.237 (Depositor), 0.234 (DCC)
• R-Value Work:  0.198 (Depositor), 0.197 (DCC)
• R-Value Observed: 0.200 (Depositor)

Space Group: I 2 3

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 147.65	α = 90
b = 147.65	β = 90
c = 147.65	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-03-04
Deposition Author(s): Niggenaber, J., Mueller, M.P., Rauh, D.

---

Funding Organization	Location	Grant Number
German Federal Ministry for Education and Research	Germany	01ZX2201B
European Regional Development Fund	European Union	EFRE-800400
Other private		Ex-2021-0033
Other government		NW21-062C

Revision History

• Version 1.0: 2026-03-04
  Type: Initial release
