9EZY

Vibrio cholerae DdmD-DdmE holo complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.56 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Molecular mechanism of plasmid elimination by the DdmDE defense system.

Loeff, L.Adams, D.W.Chanez, C.Stutzmann, S.Righi, L.Blokesch, M.Jinek, M.

(2024) Science 385: 188-194

  • DOI: https://doi.org/10.1126/science.adq0534
  • Primary Citation of Related Structures:
    9EZX, 9EZY

  • PubMed Abstract:

    Seventh pandemic Vibrio cholerae strains contain two pathogenicity islands that encode the DNA defense modules DdmABC and DdmDE. Here we use cryogenic electron microscopy to reveal the mechanistic basis for plasmid defense by DdmDE. A structure of the DdmD helicase-nuclease reveals it adopts an auto-inhibited dimeric architecture. The prokaryotic Argonaute protein DdmE uses a DNA guide to target plasmid DNA. A structure of the DdmDE complex, validated by in vivo mutational studies, shows that DNA binding by DdmE triggers disassembly of the DdmD dimer and loading of monomeric DdmD onto the non-target DNA strand. In vitro studies reveal that DdmD translocates in the 5'-to-3' direction, while partially degrading the plasmid DNA. These findings provide critical insights into the mechanism of DdmDE systems in plasmid elimination.


  • Organizational Affiliation

    Department of Biochemistry, University of Zurich, Zurich, Switzerland.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Helicase/UvrB N-terminal domain-containing protein1,193Vibrio choleraeMutation(s): 1
Gene Names: VC_1771
UniProt
Find proteins for Q9KR72 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961))
Explore Q9KR72
Go to UniProtKB:  Q9KR72
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9KR72
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Vibrio cholerae DdmE690Vibrio choleraeMutation(s): 0
Gene Names: VC_1770
UniProt
Find proteins for Q9KR73 (Vibrio cholerae serotype O1 (strain ATCC 39315 / El Tor Inaba N16961))
Explore Q9KR73
Go to UniProtKB:  Q9KR73
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9KR73
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
14 nucleotide DNA guide with terminal 5' phosphate15synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains LengthOrganismImage
Target DNA strand66synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains LengthOrganismImage
Non-target DNA strand66synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
F [auth C]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.56 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
RECONSTRUCTIONcryoSPARC4.4.1.

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Research Council (ERC)European Union820150

Revision History  (Full details and data files)

  • Version 1.0: 2024-09-04
    Type: Initial release
