9EGP | pdb_00009egp

Cryo-EM of type IV pilus from Geobacter metallireducens

PDB DOI: https://doi.org/10.2210/pdb9EGP/pdb
EM Map EMD-47993: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): Geobacter metallireducens
Mutation(s): No

Deposited: 2024-11-21 Released: 2025-11-26
Deposition Author(s): Egorova, M., Petersen, H.A., Chan, C.H., Bond, D.R., Wang, F.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.60 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 9EGP

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM of type IV pilus from Geobacter metallireducens

Egorova, M., Petersen, H.A., Chan, C.H., Bond, D.R., Wang, F.

To be published.

Macromolecule Content

Total Structure Weight: 19.44 kDa
Atom Count: 1,127
Modeled Residue Count: 151
Deposited Residue Count: 182
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Geopilin domain 2 protein	A [auth B]	113	Geobacter metallireducens	Mutation(s): 0
UniProt
Find proteins for Q39VU0 (Geobacter metallireducens (strain ATCC 53774 / DSM 7210 / GS-15)) Explore Q39VU0 Go to UniProtKB: Q39VU0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q39VU0
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Geopilin domain 1 protein	B [auth A]	69	Geobacter metallireducens	Mutation(s): 0
UniProt
Find proteins for Q39VU1 (Geobacter metallireducens (strain ATCC 53774 / DSM 7210 / GS-15)) Explore Q39VU1 Go to UniProtKB: Q39VU1
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q39VU1
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.60 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-11-26

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM138756

Revision History (Full details and data files)

Version 1.0: 2025-11-26
Type: Initial release
