9EGG | pdb_00009egg

The deep-primed conformation of herpes simplex virus type 1 (HSV-1) glycoprotein B (gB) mutant R131F

PDB DOI: https://doi.org/10.2210/pdb9EGG/pdb
EM Map EMD-47988: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Human alphaherpesvirus 1 strain F
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2024-11-21 Released: 2026-04-08
Deposition Author(s): Mou, Z., Wang, S., Dai, X.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.65 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9EGG

This is version 1.0 of the entry. See complete history.

Literature

The deep-primed conformation of herpes simplex virus type 1 (HSV-1) glycoprotein B (gB) mutant R131F

Mou, Z., Wang, S., Dai, X.

To be published.

Macromolecule Content

Total Structure Weight: 300.91 kDa
Atom Count: 11,832
Modeled Residue Count: 1,467
Deposited Residue Count: 2,688
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Envelope glycoprotein B	A, B, C	896	Human alphaherpesvirus 1 strain F	Mutation(s): 1 Gene Names: gB, UL27
UniProt
Find proteins for P06436 (Human herpesvirus 1 (strain F)) Explore P06436 Go to UniProtKB: P06436
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P06436
Glycosylation
Glycosylation Sites: 2	Glycosylation Focus chain A Focus chain B Focus chain C
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download:Ideal Coordinates CCD File SDF format, chain I [auth C] SDF format, chain H [auth C] SDF format, chain G [auth B] SDF format, chain F [auth B] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain I [auth C] MOL2 format, chain H [auth C] MOL2 format, chain G [auth B] MOL2 format, chain F [auth B] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain I [auth C] mmCIF format, chain H [auth C] mmCIF format, chain G [auth B] mmCIF format, chain F [auth B] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth B] G [auth B] H [auth C] D [auth A], E [auth A], F [auth B], G [auth B], H [auth C], I [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth C] Focus chain I [auth C] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth C] Focus chain I [auth C]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.65 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-04-08

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R35GM151043

Revision History (Full details and data files)

Version 1.0: 2026-04-08
Type: Initial release
