9DT6 | pdb_00009dt6

Crystal structure of ADP-ribose diphosphatase from Klebsiella pneumoniae (CMP bound, P21 form)

• PDB DOI: https://doi.org/10.2210/pdb9DT6/pdb

• Classification: HYDROLASE
• Organism(s): Klebsiella pneumoniae
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-09-30 Released: 2024-10-09
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.59 Å
• R-Value Free:
  0.202 (Depositor), 0.207 (DCC)
• R-Value Work:
  0.170 (Depositor), 0.179 (DCC)
• R-Value Observed:
  0.172 (Depositor)

Starting Model: experimental

Literature

Crystal structure of ADP-ribose diphosphatase from Klebsiella pneumoniae (CMP bound, P21 form)

Liu, L., Lovell, S., Buchko, G.W., Battaile, K.P.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 3 assigned by authors and generated by PISA (software)

Biological Assembly 4

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 4 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 199.24 kDa
• Atom Count: 13,926
• Modeled Residue Count: 1,578
• Deposited Residue Count: 1,744
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ADP-ribose pyrophosphatase	A, B, C, D, E, F, G, H	218	Klebsiella pneumoniae	Mutation(s): 0  Gene Names: KPHS_45750 EC: 3.6.1.13
UniProt
Find proteins for B5XU49 (Klebsiella variicola (strain 342)) Explore B5XU49  Go to UniProtKB:  B5XU49

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
C5P (Subject of Investigation/LOI)	I [auth C], J [auth E], K [auth F], L [auth H]	CYTIDINE-5'-MONOPHOSPHATE C9 H14 N3 O8 P IERHLVCPSMICTF-XVFCMESISA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.59 Å
• R-Value Free:  0.202 (Depositor), 0.207 (DCC)
• R-Value Work:  0.170 (Depositor), 0.179 (DCC)
• R-Value Observed: 0.172 (Depositor)

Diffraction Data: https://doi.org/10.18430/M39DT6

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.941	α = 90
b = 80.064	β = 90.18
c = 115.788	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2024-10-09
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394

Revision History

• Version 1.0: 2024-10-09
  Type: Initial release
