9DFA | pdb_00009dfa

Thermococcus gammatolerans DNA Ligase

• PDB DOI: https://doi.org/10.2210/pdb9DFA/pdb
• Entry: 9DFA supersedes: 6WBO

• Classification: DNA BINDING PROTEIN,LIGASE
• Organism(s): Thermococcus gammatolerans EJ3
• Expression System: Escherichia coli BL21
• Mutation(s): No


• Deposited: 2024-08-29 Released: 2026-03-18
• Deposition Author(s): Rudino-Pinera, E., Quintana-Armas, A.X., Cardona-Felix, C., Flores-Hernandez, E.
• Funding Organization(s): Programa de Apoyo a Proyectos de Investigacion e Innovacion Tecnologica (PAPIIT), Consejo Nacional de Ciencia y Tecnologia (CONACYT)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.17 Å
• R-Value Free:
  0.258 (Depositor), 0.258 (DCC)
• R-Value Work:
  0.215 (Depositor), 0.215 (DCC)
• R-Value Observed:
  0.217 (Depositor)

Starting Model: experimental

Literature

Unveiling Structural Intermediaries of the Ligation Mechanism and Conserved Mobility Patterns in ATP-Dependent DNA Ligases

Rudino-Pinera, E., Quintana-Armas, A.X., Cardona-Felix, C., Flores-Hernandez, E.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 64.28 kDa
• Atom Count: 4,579
• Modeled Residue Count: 556
• Deposited Residue Count: 560
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA ligase	A	560	Thermococcus gammatolerans EJ3	Mutation(s): 0  Gene Names: lig, TGAM_1718 EC: 6.5.1.6
UniProt
Find proteins for C5A7K8 (Thermococcus gammatolerans (strain DSM 15229 / JCM 11827 / EJ3)) Explore C5A7K8  Go to UniProtKB:  C5A7K8

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
AMP (Subject of Investigation/LOI)	C [auth A]	ADENOSINE MONOPHOSPHATE C10 H14 N5 O7 P UDMBCSSLTHHNCD-KQYNXXCUSA-N
PO4 (Subject of Investigation/LOI)	B [auth A], D [auth A]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.17 Å
• R-Value Free:  0.258 (Depositor), 0.258 (DCC)
• R-Value Work:  0.215 (Depositor), 0.215 (DCC)
• R-Value Observed: 0.217 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.65	α = 90
b = 93.7	β = 90
c = 97.05	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2026-03-18
Deposition Author(s): Rudino-Pinera, E., Quintana-Armas, A.X., Cardona-Felix, C., Flores-Hernandez, E.
• This entry supersedes: 6WBO

---

Funding Organization	Location	Grant Number
Programa de Apoyo a Proyectos de Investigacion e Innovacion Tecnologica (PAPIIT)	Mexico	IN226523
Consejo Nacional de Ciencia y Tecnologia (CONACYT)	Mexico	2019-000037-02NACF-23048

Revision History

• Version 1.0: 2026-03-18
  Type: Initial release
