9DAY | pdb_00009day

Crystal Structure of the Transcriptional Regulator HcpR from Porphyromonas Gingivalis

• PDB DOI: https://doi.org/10.2210/pdb9DAY/pdb

• Classification: TRANSCRIPTION
• Organism(s): Porphyromonas gingivalis
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-08-22 Released: 2026-01-28
• Deposition Author(s): Musayev, F.N., Escalante, C.R., Belvin, B.R., Lewis, J.P.
• Funding Organization(s): National Institutes of Health/National Institute of Dental and Craniofacial Research (NIH/NIDCR)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.256 (Depositor), 0.255 (DCC)
• R-Value Work:
  0.215 (Depositor), 0.215 (DCC)
• R-Value Observed:
  0.217 (Depositor)

Starting Model: experimental

Literature

Structure of the Wild Type NO sensing transcription factor HcpR

Belvin, B.R., Musayev, F.N., Escalante, C., Lewis, J.P.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 55.22 kDa
• Atom Count: 3,673
• Modeled Residue Count: 465
• Deposited Residue Count: 484
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transcriptional regulator, putative	A, B	242	Porphyromonas gingivalis	Mutation(s): 0  Gene Names: PG_1053
UniProt
Find proteins for Q7MVK4 (Porphyromonas gingivalis (strain ATCC BAA-308 / W83)) Explore Q7MVK4  Go to UniProtKB:  Q7MVK4

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL (Subject of Investigation/LOI)	C [auth A], D [auth A], G [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
FMT (Subject of Investigation/LOI)	E [auth A], F [auth A]	FORMIC ACID C H2 O2 BDAGIHXWWSANSR-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.256 (Depositor), 0.255 (DCC)
• R-Value Work:  0.215 (Depositor), 0.215 (DCC)
• R-Value Observed: 0.217 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 106.281	α = 90
b = 106.281	β = 90
c = 116.773	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
CrysalisPro	data reduction
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-01-28
Deposition Author(s): Musayev, F.N., Escalante, C.R., Belvin, B.R., Lewis, J.P.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of Dental and Craniofacial Research (NIH/NIDCR)	United States	2R01DE023304

Revision History

• Version 1.0: 2026-01-28
  Type: Initial release
