9CK0

Cocrystal of PPARg LBD and NFKBIB / IKBB peptide with agonist GW1929

  • Classification: DNA BINDING PROTEIN
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2024-07-08 Released: 2024-07-17
  • Deposition Author(s): Nemetchek, M.D., McClelland, L.J., Hughes, T.S.
  • Funding Organization(s): National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.250
  • R-Value Observed: 0.255

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history.


Literature

Cocrystal of PPARg LBD with NFKBIB / IKBB peptide containing N-anchor motif LxxLL and agonist GW1929

Nemetchek, M.D., Hughes, T.S.

To be published.

Macromolecules
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Peroxisome proliferator-activated receptor gamma276Homo sapiensMutation(s): 0
Gene Names: PPARG, NR1C3
UniProt & NIH Common Fund Data Resources
Find proteins for P37231 (Homo sapiens)
Explore P37231
Go to UniProtKB:  P37231
PHAROS:  P37231
GTEx:  ENSG00000132170
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP37231
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
NF-kappa-B inhibitor beta23Homo sapiensMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q15653 (Homo sapiens)
Explore Q15653
Go to UniProtKB:  Q15653
PHAROS:  Q15653
GTEx:  ENSG00000104825
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15653
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
EDK (Subject of Investigation/LOI)
Query on EDK
Download Ideal Coordinates CCD File
C [auth A](2~{S})-3-[4-[2-[methyl(pyridin-2-yl)amino]ethoxy]phenyl]-2-[[2-(phenylcarbonyl)phenyl]amino]propanoic acid
C30 H29 N3 O4
QTQMRBZOBKYXCG-MHZLTWQESA-N
Binding Affinity Annotations
IDSourceBinding Affinity
EDK BindingDB:  9CK0 Ki: min: 0.05, max: 104 (nM) from 6 assay(s)
EC50: min: 1.5, max: 389 (nM) from 16 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.296
  • R-Value Work: 0.250
  • R-Value Observed: 0.255
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.53α = 90
b = 89.5β = 90
c = 121.545γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK)United StatesR01DK129646
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP30GM140963

Revision History  (Full details and data files)

  • Version 1.0: 2024-07-17
    Type: Initial release
