9CI4 | pdb_00009ci4

Crystal structure of Fe/2-OG dependent dioxygenase MysH (Apo form)

PDB DOI: https://doi.org/10.2210/pdb9CI4/pdb

Classification: METAL BINDING PROTEIN
Organism(s): Nostoc linckia NIES-25
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-07-02 Released: 2026-03-18
Deposition Author(s): Wanniarachchi, T.N., Bruner, S.D.
Funding Organization(s): National Science Foundation (NSF, United States)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.204 (Depositor), 0.204 (DCC)
R-Value Work:
0.175 (Depositor), 0.176 (DCC)
R-Value Observed:
0.177 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of non-heme iron and alpha-ketoglutarate dependent dioxygenase MysH

Wanniarachchi, T.N., Bruner, S.D.

To be published.

Macromolecule Content

Total Structure Weight: 31.24 kDa
Atom Count: 2,248
Modeled Residue Count: 248
Deposited Residue Count: 270
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Fe/2-OG dependent dioxygenase MysH	A	270	Nostoc linckia NIES-25	Mutation(s): 0 Gene Names: VF08_32425
UniProt
Find proteins for A0A9Q5Z5X5 (Nostoc linckia z8) Explore A0A9Q5Z5X5 Go to UniProtKB: A0A9Q5Z5X5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A9Q5Z5X5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CIT Query on CIT Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	CITRIC ACID C₆ H₈ O₇ KRKNYBCHXYNGOX-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.204 (Depositor), 0.204 (DCC)
R-Value Work: 0.175 (Depositor), 0.176 (DCC)
R-Value Observed: 0.177 (Depositor)

Space Group: P 3₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 44.419	α = 90
b = 44.419	β = 90
c = 107.754	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2026-03-18

Deposition Author(s):

Wanniarachchi, T.N.

Funding Organization	Location	Grant Number
National Science Foundation (NSF, United States)	United States	2108383

Revision History (Full details and data files)

Version 1.0: 2026-03-18
Type: Initial release
