9C6D | pdb_00009c6d

Crystal structure of mutant NonPro1 Tautomerase Superfamily Member 8U6-S1P in complex with 3-bromopropiolate inhibitor


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:
    0.253 (Depositor), 0.252 (DCC)
  • R-Value Work:
    0.197 (Depositor), 0.196 (DCC)
  • R-Value Observed:
    0.199 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9C6D

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

Conversion of Inactive Non-Pro1 Tautomerase Superfamily Members into Active Tautomerases: Analysis of the Pro1 Mutants.

Lancaster, E.B.Hardtke, H.A.Melkonian, T.R.Venkat Ramani, M.Johnson Jr., W.H.Baas, B.J.Zhang, Y.J.Whitman, C.P.

(2025) Biochemistry 64: 812-822

  • DOI: https://doi.org/10.1021/acs.biochem.4c00338
  • Primary Citation Related Structures:
    9C4L, 9C6D

  • PubMed Abstract:

    Pro1 is a critical catalytic residue in the characterized activities of tautomerase superfamily (TSF) members. Only a handful of members (∼346) lack Pro1 in a sequence similarity network (SSN) that consists of over 11,000 members. Most (294 members) are in the malonate semialdehyde decarboxylase (MSAD)-like subgroup, but the ones characterized thus far have little or no MSAD activity. Moreover, there is little to no activity with other TSF substrates. Five non-Pro1 members were selected randomly for kinetic [using phenylenolpyruvate (PP) and 2-hydroxymuconate (2HM)], mutagenic, inhibition, and crystallographic analysis. Using PP, k cat / K m values (∼10 1 -10 2 M -1 s -1 ) could be estimated for three native proteins whereas using 2HM, a k cat / K m value could only be estimated for one native protein (∼10 3 M -1 s -1 ). The k cat and K m values could not be determined. However, changing the N-terminal residue to a proline gave a significant improvement in k cat / K m values for all mutant enzymes using PP or 2HM. For PP, the k cat / K m values ranged from 10 3 -10 5 M -1 s -1 and for 2HM, the k cat / K m values ranged from 10 2 -10 4 M -1 s -1 . In addition, it was now possible to measure k cat and K m values for all mutant proteins using PP and one mutant protein using 2HM. Incubation of the Pro1 mutants with 3-bromopropiolate (3BP) results in covalent modification of the prolyl nitrogen of Pro1 by a 3-oxopropanoate adduct. Crystallographic analysis of two mutant enzymes (NJ7V1P and 8U6S1P) modified by the 3-oxopropanoate adduct identified binding ligands and suggest a mechanism for the tautomerase activity involving Pro1, Arg71, Tyr124, and the backbone amide of Phe68.


  • Organizational Affiliation
    • Division of Chemical Biology and Medicinal Chemistry, College of Pharmacy, The University of Texas at Austin, Austin, Texas 78712, United States.

Macromolecule Content

  • Total Structure Weight: 89.69 kDa
  • Atom Count: 6,058
  • Modeled Residue Count: 713
  • Deposited Residue Count: 768
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Tautomerase family protein
A, B, C, D, E
A, B, C, D, E, F
128SulfurovumMutation(s): 1
Gene Names: SUN_0947
UniProt
Find proteins for A0ACD6B9B4 (Sulfurovum sp. (strain NBC37-1))
Explore A0ACD6B9B4
Go to UniProtKB:  A0ACD6B9B4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0ACD6B9B4
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free:  0.253 (Depositor), 0.252 (DCC)
  • R-Value Work:  0.197 (Depositor), 0.196 (DCC)
  • R-Value Observed: 0.199 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.879α = 90
b = 91.975β = 96.74
c = 138.948γ = 90
Software Package:
Software NamePurpose
PHENIXphasing
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Robert A. Welch FoundationUnited StatesF-2125
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM-26168171

Revision History  (Full details and data files)

  • Version 1.0: 2025-03-05
    Type: Initial release
