9BE1

CG-centric NF-kappaB RelA binding DNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.349
  • R-Value Work: 0.298
  • R-Value Observed: 0.301

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Transient interactions modulate the affinity of NF-kappa B transcription factors for DNA.

Li, T.Shahabi, S.Biswas, T.Tsodikov, O.V.Pan, W.Huang, D.B.Wang, V.Y.Wang, Y.Ghosh, G.

(2024) Proc Natl Acad Sci U S A 121: e2405555121-e2405555121

  • DOI: https://doi.org/10.1073/pnas.2405555121
  • Primary Citation of Related Structures:
    9BDU, 9BDV, 9BDW, 9BDX, 9BDY, 9BDZ, 9BE0, 9BE1

  • PubMed Abstract:

    The dimeric nuclear factor kappa B (NF-κB) transcription factors (TFs) regulate gene expression by binding to a variety of κB DNA elements with conserved G:C-rich flanking sequences enclosing a degenerate central region. Toward defining mechanistic principles of affinity regulated by degeneracy, we observed an unusual dependence of the affinity of RelA on the identity of the central base pair, which appears to be noncontacted in the complex crystal structures. The affinity of κB sites with A or T at the central position is ~10-fold higher than with G or C. The crystal structures of neither the complexes nor the free κB DNAs could explain the differences in affinity. Interestingly, differential dynamics of several residues were revealed in molecular dynamics simulation studies, where simulation replicates totaling 148 μs were performed on NF-κB:DNA complexes and free κB DNAs. Notably, Arg187 and Arg124 exhibited selectivity in transient interactions that orchestrated a complex interplay among several DNA-interacting residues in the central region. Binding and simulation studies with mutants supported these observations of transient interactions dictating specificity. In combination with published reports, this work provides insights into the nuanced mechanisms governing the discriminatory binding of NF-κB family TFs to κB DNA elements and sheds light on cancer pathogenesis of cRel, a close homolog of RelA.


  • Organizational Affiliation

    Department of Physics, The Chinese University of Hong Kong, Shatin, Hong Kong Special Administrative Region 999077, China.


Macromolecules

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(*CP*GP*GP*GP*AP*AP*TP*TP*TP*CP*CP*GP*CP*GP*GP*AP*AP*AP*TP*TP*CP*CP*CP*G)-3')12Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*CP*GP*GP*GP*AP*AP*TP*TP*TP*CP*CP*GP*CP*GP*GP*AP*AP*AP*TP*TP*CP*CP*CP*G)-3')12Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
AA [auth A]
AB [auth X]
AC [auth f]
AD [auth l]
AE [auth r]
AA [auth A],
AB [auth X],
AC [auth f],
AD [auth l],
AE [auth r],
BB [auth I],
BC [auth f],
BD [auth l],
BE [auth r],
CA [auth P],
CB [auth I],
CC [auth Y],
CD [auth S],
CE [auth r],
DA [auth P],
DB [auth I],
DC [auth Y],
DD [auth S],
EA [auth P],
EB [auth b],
EC [auth Y],
ED [auth S],
FA [auth P],
FB [auth b],
FC [auth Y],
FD [auth S],
GA [auth E],
GB [auth b],
GC [auth h],
GD [auth n],
HA [auth E],
HB [auth b],
HC [auth h],
HD [auth n],
IA [auth E],
IB [auth b],
IC [auth h],
ID [auth n],
JB [auth K],
JC [auth h],
JD [auth n],
KA [auth E],
KC [auth h],
KD [auth n],
LA [auth T],
LB [auth K],
LC [auth W],
LD [auth Q],
MA [auth T],
MB [auth K],
MC [auth W],
MD [auth Q],
NB [auth K],
NC [auth W],
ND [auth Q],
OA [auth T],
OB [auth d],
OC [auth j],
OD [auth Q],
PA [auth T],
PB [auth d],
PC [auth j],
PD [auth p],
QA [auth T],
QB [auth d],
QC [auth j],
QD [auth p],
RA [auth G],
RB [auth d],
RC [auth j],
RD [auth p],
SB [auth d],
SC [auth j],
SD [auth p],
TA [auth G],
TB [auth N],
TC [auth U],
TD [auth p],
UA [auth G],
UB [auth N],
UC [auth U],
UD [auth M],
VA [auth G],
VB [auth N],
VC [auth U],
VD [auth M],
WA [auth X],
WB [auth N],
WC [auth U],
WD [auth M],
XA [auth X],
XB [auth f],
XC [auth l],
Y [auth A],
YA [auth X],
YB [auth f],
YC [auth l],
YD [auth r],
Z [auth A],
ZA [auth X],
ZB [auth f],
ZC [auth l],
ZD [auth r]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
ACT
Query on ACT

Download Ideal Coordinates CCD File
BA [auth P]
JA [auth E]
KB [auth K]
NA [auth T]
SA [auth G]
BA [auth P],
JA [auth E],
KB [auth K],
NA [auth T],
SA [auth G],
XD [auth r]
ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.60 Å
  • R-Value Free: 0.349
  • R-Value Work: 0.298
  • R-Value Observed: 0.301
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.999α = 90.03
b = 47.031β = 89.96
c = 98.682γ = 59.99
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
HKL-2000data scaling
SHELXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01 GM085490-11

Revision History  (Full details and data files)

  • Version 1.0: 2024-08-07
    Type: Initial release
  • Version 1.1: 2024-08-21
    Changes: Derived calculations
