8ZNT | pdb_00008znt

Catalytic antibody T99_C220A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.61 Å
  • R-Value Free:
    0.254 (Depositor), 0.254 (DCC)
  • R-Value Work:
    0.195 (Depositor), 0.197 (DCC)
  • R-Value Observed:
    0.197 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8ZNT

This is version 1.0 of the entry. See complete history

Literature

Structural and biochemical differences between non-catalytic and catalytic antibodies.

Uda, T.Kato, R.Shigeta, Y.Hirota, S.Kobayashi, J.Yoshida, H.Tsuyuguchi, M.Hengphasatporn, K.Tsujita, M.Taguchi, H.Hifumi, E.

(2025) MAbs 17: 2503978-2503978

  • DOI: https://doi.org/10.1080/19420862.2025.2503978
  • Primary Citation Related Structures:
    8ZNT, 8ZNU

  • PubMed Abstract:

    A conventional antibody can be converted into its catalytic counterparts by deleting Pro95 in the CDR-3 of human and mice antibody light chains, as previously reported. T99wt is a naturally occurring human antibody light chain that we transformed into its catalytic antibody using Pro95 deletion. In peptidase activity tests, T99wt exhibited a low catalytic activity against a synthetic peptide Arg-pNA and hardly cleaved amyloid-β peptide. In contrast, the engineered variant (T99-Pro95(-)) demonstrated significant catalytic activity, effectively cleaving both Arg-pNA substrate and amyloid-β peptides. In this study, the structural basis for the acquisition of enzymatic function through Pro95 deletion in the CDR-3 region of the light chain was elucidated using X-ray crystallography and molecular dynamics (MD) simulations. X-ray crystallography revealed that Pro95 deletion substantially reduces the distance between Asp1 and His93-key residues for catalytic activity - from 9.56 Å in T99wt to 3.84 Å in T99-Pro95(-). The observed decrease in distance indicates a strong interaction between Asp1(Oδ1) and His93(Nε2), contributing to the formation of an active site in T99-Pro95(-). MD simulations revealed that the entire structure exhibits slight fluctuations and adopts various configurations upon the removal of Pro95. In particular, when His residues in the catalytic region are fully deprotonated, Asp1, His93, and Ser27a transiently come into close proximity, enabling the formation of a functional catalytic triad. Catalytic antibodies can be made starting from just the amino acid sequence of a desired mAb, which may be available in databases such as OAS or IMGT. Therefore, our finding represents a significant technological advancement.


  • Organizational Affiliation
    • Research Center for GLOBAL/LOCAL Infectious Diseases, Oita University, Oita-shi, Oita, Japan.

Macromolecule Content

  • Total Structure Weight: 203.44 kDa
  • Atom Count: 13,868
  • Modeled Residue Count: 1,748
  • Deposited Residue Count: 1,808
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Catalytic antibody T99_C220A
A, B, C, D, E
A, B, C, D, E, F, G, H
226Homo sapiensMutation(s): 0

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PEG

Query on PEG



Download:Ideal Coordinates CCD File
EC [auth G],
Q [auth A]
DI(HYDROXYETHYL)ETHER
C4 H10 O3
MTHSVFCYNBDYFN-UHFFFAOYSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
AB [auth E]
BB [auth E]
DA [auth C]
I [auth A]
IC [auth H]
AB [auth E],
BB [auth E],
DA [auth C],
I [auth A],
IC [auth H],
KB [auth F],
LB [auth F],
MB [auth F],
T [auth B],
UB [auth G],
VB [auth G],
WB [auth G],
XB [auth G],
YA [auth E],
YB [auth G],
ZA [auth E]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
AC [auth G]
BC [auth G]
CB [auth E]
CC [auth G]
DB [auth E]
AC [auth G],
BC [auth G],
CB [auth E],
CC [auth G],
DB [auth E],
DC [auth G],
EA [auth C],
EB [auth E],
FA [auth C],
FB [auth E],
GA [auth C],
GB [auth E],
HA [auth C],
IA [auth C],
J [auth A],
JA [auth C],
JC [auth H],
K [auth A],
KA [auth C],
KC [auth H],
L [auth A],
LC [auth H],
M [auth A],
MC [auth H],
N [auth A],
NA [auth D],
NB [auth F],
NC [auth H],
O [auth A],
OA [auth D],
OB [auth F],
OC [auth H],
P [auth A],
PA [auth D],
PB [auth F],
QA [auth D],
QB [auth F],
RA [auth D],
RB [auth F],
SA [auth D],
TA [auth D],
U [auth B],
UA [auth D],
V [auth B],
W [auth B],
X [auth B],
ZB [auth G]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N
K

Query on K



Download:Ideal Coordinates CCD File
FC [auth G]
HB [auth E]
LA [auth C]
PC [auth H]
R [auth A]
FC [auth G],
HB [auth E],
LA [auth C],
PC [auth H],
R [auth A],
SB [auth F],
VA [auth D],
Y [auth B],
Z [auth B]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
CL

Query on CL



Download:Ideal Coordinates CCD File
AA [auth B]
BA [auth B]
CA [auth B]
GC [auth G]
HC [auth G]
AA [auth B],
BA [auth B],
CA [auth B],
GC [auth G],
HC [auth G],
IB [auth E],
JB [auth E],
MA [auth C],
QC [auth H],
S [auth A],
TB [auth F],
WA [auth D],
XA [auth D]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.61 Å
  • R-Value Free:  0.254 (Depositor), 0.254 (DCC)
  • R-Value Work:  0.195 (Depositor), 0.197 (DCC)
  • R-Value Observed: 0.197 (Depositor)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 77.085α = 106.772
b = 85.326β = 91.437
c = 104.58γ = 116.914
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Agency for Medical Research and Development (AMED)JapanJP21am0101083

Revision History  (Full details and data files)

  • Version 1.0: 2025-05-28
    Type: Initial release
