8XUW | pdb_00008xuw

Crystal Structure of the bromodomain of Fusarium graminearum GCN5

PDB DOI: https://doi.org/10.2210/pdb8XUW/pdb

Classification: TRANSCRIPTION
Organism(s): Fusarium graminearum
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-01-14 Released: 2025-04-23
Deposition Author(s): Li, L., Ran, T., Wang, W., Zhang, F.
Funding Organization(s): National Basic Research Program of China (973 Program)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.58 Å
R-Value Free:
0.204 (Depositor), 0.205 (DCC)
R-Value Work:
0.189 (Depositor), 0.188 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8XUW

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of the bromodomain of Fusarium graminearum GCN5

Li, L., Ran, T., Wang, W., Zhang, F.

To be published.

Macromolecule Content

Total Structure Weight: 13.93 kDa
Atom Count: 1,110
Modeled Residue Count: 112
Deposited Residue Count: 117
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Histone acetyltransferase GCN5	A	117	Fusarium graminearum	Mutation(s): 0 Gene Names: FUG_LOCUS431635, MDCFG202_LOCUS278190 EC: 2.3.1.48
UniProt
Find proteins for A0A2H3G405 (Gibberella zeae) Explore A0A2H3G405 Go to UniProtKB: A0A2H3G405
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A2H3G405
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.58 Å
R-Value Free: 0.204 (Depositor), 0.205 (DCC)
R-Value Work: 0.189 (Depositor), 0.188 (DCC)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.582	α = 90
b = 74.977	β = 90
c = 50.106	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-04-23

Deposition Author(s):

Funding Organization	Location	Grant Number
National Basic Research Program of China (973 Program)	China	2022YFD1700300

Revision History (Full details and data files)

Version 1.0: 2025-04-23
Type: Initial release
