8XFY | pdb_00008xfy

The Crystal Structure of RSK2 from Biortus.

PDB DOI: https://doi.org/10.2210/pdb8XFY/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: unidentified baculovirus
Mutation(s): No

Deposited: 2023-12-14 Released: 2024-03-06
Deposition Author(s): Wang, F., Cheng, W., Lv, Z., Lin, D., Pan, W.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.20 Å
R-Value Free:
0.303 (Depositor), 0.299 (DCC)
R-Value Work:
0.229 (Depositor), 0.231 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

The Crystal Structure of RSK2 from Biortus.

Wang, F., Cheng, W., Lv, Z., Lin, D., Pan, W.

To be published.

Macromolecule Content

Total Structure Weight: 373.05 kDa
Atom Count: 22,210
Modeled Residue Count: 2,684
Deposited Residue Count: 3,200
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ribosomal protein S6 kinase alpha-3	A, B, C, D, E A, B, C, D, E, F, G, H, I, J	320	Homo sapiens	Mutation(s): 0 Gene Names: RPS6KA3 EC: 2.7.11.1
UniProt & NIH Common Fund Data Resources
Find proteins for P51812 (Homo sapiens) Explore P51812 Go to UniProtKB: P51812
PHAROS: P51812 GTEx: ENSG00000177189
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P51812
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1LU8 (Subject of Investigation/LOI) Query on A1LU8 Download:Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain M [auth C] SDF format, chain N [auth D] SDF format, chain P [auth F] SDF format, chain S [auth I] SDF format, chain T [auth J] SDF format, chain R [auth H] SDF format, chain Q [auth G] SDF format, chain O [auth E] SDF format, chain K [auth A] MOL2 format, chain L [auth B] MOL2 format, chain M [auth C] MOL2 format, chain N [auth D] MOL2 format, chain P [auth F] MOL2 format, chain S [auth I] MOL2 format, chain T [auth J] MOL2 format, chain R [auth H] MOL2 format, chain Q [auth G] MOL2 format, chain O [auth E] MOL2 format, chain K [auth A] mmCIF format, chain L [auth B] mmCIF format, chain M [auth C] mmCIF format, chain N [auth D] mmCIF format, chain P [auth F] mmCIF format, chain S [auth I] mmCIF format, chain T [auth J] mmCIF format, chain R [auth H] mmCIF format, chain Q [auth G] mmCIF format, chain O [auth E] mmCIF format, chain K [auth A]	K [auth A] L [auth B] M [auth C] N [auth D] O [auth E] K [auth A], L [auth B], M [auth C], N [auth D], O [auth E], P [auth F], Q [auth G], R [auth H], S [auth I], T [auth J]	2,6-bis(fluoranyl)-4-[4-(4-morpholin-4-ylphenyl)pyridin-3-yl]phenol C₂₁ H₁₈ F₂ N₂ O₂ YUYJEQHNWKQNBT-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain L [auth B] Focus chain M [auth C] Focus chain N [auth D] Focus chain O [auth E] Focus chain P [auth F] Focus chain Q [auth G] Focus chain R [auth H] Focus chain S [auth I] Focus chain T [auth J] Interactions & Density Focus chain K [auth A] Focus chain L [auth B] Focus chain M [auth C] Focus chain N [auth D] Focus chain O [auth E] Focus chain P [auth F] Focus chain Q [auth G] Focus chain R [auth H] Focus chain S [auth I] Focus chain T [auth J]
