8WOC | pdb_00008woc

Cryo-EM structure of SIR2/HerA complex

PDB DOI: https://doi.org/10.2210/pdb8WOC/pdb
EM Map EMD-37682: EMDB EMDataResource

Classification: IMMUNE SYSTEM
Organism(s): Paenibacillus sp. 453mf
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2023-10-07 Released: 2024-09-11
Deposition Author(s): Yu, G., Liao, F., Li, X., Li, Z., Zhang, H.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.28 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8WOC

This is version 1.1 of the entry. See complete history.

Literature

Cryo-EM structure of a bacterial protein

Yu, G., Liao, F., Li, X., Li, Z., Zhang, H.

To be published.

Macromolecule Content

Total Structure Weight: 771.02 kDa
Atom Count: 41,220
Modeled Residue Count: 5,845
Deposited Residue Count: 6,843
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Helicase HerA central domain-containing protein	A B [auth D] E [auth L] F [auth M] G [auth N] A, B [auth D], E [auth L], F [auth M], G [auth N], H [auth O]	696	Paenibacillus sp. 453mf	Mutation(s): 0 Gene Names: SAMN04488601_104156

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
SIR2-like domain-containing protein	C [auth J] D [auth K] I [auth P] J [auth Q] K [auth R] C [auth J], D [auth K], I [auth P], J [auth Q], K [auth R], L [auth S], M [auth T]	381	Paenibacillus sp. 453mf	Mutation(s): 0 Gene Names: SAMN04488601_104157
UniProt
Find proteins for A0ACD6BAK5 (Paenibacillus sp. 453mf) Explore A0ACD6BAK5 Go to UniProtKB: A0ACD6BAK5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0ACD6BAK5
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.28 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-09-11

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32200496

Revision History (Full details and data files)

Version 1.0: 2024-09-11
Type: Initial release
Version 1.1: 2025-07-02
Changes: Data collection, Structure summary
