8WD3 | pdb_00008wd3

The Crystal Structure of JMJD2A(M1-L359) from Biortus.

PDB DOI: https://doi.org/10.2210/pdb8WD3/pdb

Classification: OXIDOREDUCTASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-09-14 Released: 2023-11-22
Deposition Author(s): Wang, F., Cheng, W., Lv, Z., Ju, C., Bao, C.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.30 Å
R-Value Free:
0.293 (Depositor), 0.292 (DCC)
R-Value Work:
0.244 (Depositor), 0.246 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8WD3

This is version 1.0 of the entry. See complete history.

Literature

The Crystal Structure of JMJD2A(M1-L359) from Biortus.

Wang, F., Cheng, W., Yuan, Z., Shang, H.

To be published.

Macromolecule Content

Total Structure Weight: 88.9 kDa
Atom Count: 5,512
Modeled Residue Count: 683
Deposited Residue Count: 762
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysine-specific demethylase 4A	A, B	381	Homo sapiens	Mutation(s): 0 Gene Names: KDM4A EC: 1.14.11.66 (UniProt), 1.14.11.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for O75164 (Homo sapiens) Explore O75164 Go to UniProtKB: O75164
PHAROS: O75164 GTEx: ENSG00000066135
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O75164
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN (Subject of Investigation/LOI) Query on ZN Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain F [auth B] MOL2 format, chain D [auth A] MOL2 format, chain F [auth B] mmCIF format, chain D [auth A] mmCIF format, chain F [auth B]	D [auth A], F [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain F [auth B] Interactions & Density Focus chain D [auth A] Focus chain F [auth B]
NI (Subject of Investigation/LOI) Query on NI Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain E [auth B] MOL2 format, chain C [auth A] MOL2 format, chain E [auth B] mmCIF format, chain C [auth A] mmCIF format, chain E [auth B]	C [auth A], E [auth B]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain E [auth B] Interactions & Density Focus chain C [auth A] Focus chain E [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.30 Å
R-Value Free: 0.293 (Depositor), 0.292 (DCC)
R-Value Work: 0.244 (Depositor), 0.246 (DCC)

Space Group: P 2 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 51.641	α = 90
b = 97.111	β = 90
c = 141.083	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-11-22

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2023-11-22
Type: Initial release
