8VW5 | pdb_00008vw5

Crystal structure of Cbl-b TKB bound to compound 2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free:
    0.204 (Depositor), 0.189 (DCC)
  • R-Value Work:
    0.175 (Depositor), 0.184 (DCC)
  • R-Value Observed:
    0.177 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8VW5

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

Optimization of a Novel DEL Hit That Binds in the Cbl-b SH2 Domain and Blocks Substrate Binding.

Liang, J.Lambrecht, M.J.Arenzana, T.L.Aubert-Nicol, S.Bao, L.Broccatelli, F.Cai, J.Eidenschenk, C.Everett, C.Garner, T.Gruber, F.Haghshenas, P.Huestis, M.P.Hsu, P.L.Kou, P.Jakalian, A.Larouche-Gauthier, R.Leclerc, J.P.Leung, D.H.Martin, A.Murray, J.Prangley, M.Rutz, S.Kakiuchi-Kiyota, S.Satz, A.L.Skelton, N.J.Steffek, M.Stoffler, D.Sudhamsu, J.Tan, S.Wang, J.Wang, S.Wang, Q.Wendorff, T.J.Wichert, M.Yadav, A.Yu, C.Wang, X.

(2024) ACS Med Chem Lett 15: 864-872

  • DOI: https://doi.org/10.1021/acsmedchemlett.4c00068
  • Primary Citation Related Structures:
    8VW4, 8VW5

  • PubMed Abstract:

    We were attracted to the therapeutic potential of inhibiting Casitas B-lineage lymphoma proto-oncogene-b (Cbl-b), a RING E3 ligase that plays a critical role in regulating the activation of T cells. However, given that only protein-protein interactions were involved, it was unclear whether inhibition by a small molecule would be a viable approach. After screening an ∼6 billion member DNA-encoded library (DEL) using activated Cbl-b, we identified compound 1 as a hit for which the cis -isomer ( 2 ) was confirmed by biochemical and surface plasmon resonance (SPR) assays. Our hit optimization effort was greatly accelerated when we obtained a cocrystal structure of 2 with Cbl-b, which demonstrated induced binding at the substrate binding site, namely, the Src homology-2 (SH2) domain. This was quite noteworthy given that there are few reports of small molecule inhibitors that bind to SH2 domains and block protein-protein interactions. Structure- and property-guided optimization led to compound 27 , which demonstrated measurable cell activity, albeit only at high concentrations.


  • Organizational Affiliation
    • Genentech, Inc., 1 DNA Way, South San Francisco, California 94080, United States.

Macromolecule Content

  • Total Structure Weight: 73.89 kDa
  • Atom Count: 5,746
  • Modeled Residue Count: 608
  • Deposited Residue Count: 620
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase CBL-B310Homo sapiensMutation(s): 0
Gene Names: CBLBRNF56Nbla00127
EC: 2.3.2.27
UniProt & NIH Common Fund Data Resources
Find proteins for Q13191 (Homo sapiens)
Explore Q13191
Go to UniProtKB:  Q13191
PHAROS:  Q13191
GTEx:  ENSG00000114423
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13191
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase CBL-B310Homo sapiensMutation(s): 0
Gene Names: CBLBRNF56Nbla00127
EC: 2.3.2.27
UniProt & NIH Common Fund Data Resources
Find proteins for Q13191 (Homo sapiens)
Explore Q13191
Go to UniProtKB:  Q13191
PHAROS:  Q13191
GTEx:  ENSG00000114423
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ13191
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.76 Å
  • R-Value Free:  0.204 (Depositor), 0.189 (DCC)
  • R-Value Work:  0.175 (Depositor), 0.184 (DCC)
  • R-Value Observed: 0.177 (Depositor)
Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 55.198α = 102.9
b = 56.82β = 96.55
c = 71.568γ = 111.97
Software Package:
Software NamePurpose
XDSdata reduction
Aimlessdata scaling
PHASERphasing
PHENIXrefinement

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other privateUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2024-07-03
    Type: Initial release
