8V4H

X-ray structure of the NADP-dependent reductase from Campylobacter jejuni responsible for the synthesis of CDP-glucitol in the presence of CDP-glucitol


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.207
  • R-Value Observed: 0.211

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Biosynthesis of Cytidine Diphosphate-6-d-Glucitol for the Capsular Polysaccharides of Campylobacter jejuni.

Ghosh, M.K.Narindoshvili, T.Thoden, J.B.Schumann, M.E.Holden, H.M.Raushel, F.M.

(2024) Biochemistry 63: 699-710

  • DOI: https://doi.org/10.1021/acs.biochem.3c00706
  • Primary Citation of Related Structures:
    8V4G, 8V4H

  • PubMed Abstract:

    Campylobacter jejuni is a Gram-negative pathogenic bacterium commonly found in chickens and is the leading cause of human diarrheal disease worldwide. The various serotypes of C. jejuni produce structurally distinct capsular polysaccharides (CPSs) on the exterior surfaces of the cell wall. The capsular polysaccharide from C. jejuni serotype HS:5 is composed of a repeating sequence of d- glycero -d- manno -heptose and d-glucitol-6-phosphate. We previously defined the pathway for the production of d- glycero -d- manno -heptose in C. jejuni . Here, we elucidate the biosynthetic pathway for the assembly of cytidine diphosphate (CDP)-6-d-glucitol by the combined action of two previously uncharacterized enzymes. The first enzyme catalyzes the formation of CDP-6-d-fructose from cytidine triphosphate (CTP) and d-fructose-6-phosphate. The second enzyme reduces CDP-6-d-fructose with NADPH to generate CDP-6-d-glucitol. Using sequence similarity network (SSN) and genome neighborhood network (GNN) analyses, we predict that these pairs of proteins are responsible for the biosynthesis of CDP-6-d-glucitol and/or CDP-d-mannitol in the lipopolysaccharides (LPSs) and capsular polysaccharides in more than 200 other organisms. In addition, high resolution X-ray structures of the second enzyme are reported, which provide novel insight into the manner in which an open-chain nucleotide-linked sugar is harbored in an active site cleft.


  • Organizational Affiliation

    Department of Chemistry, Texas A&M University, College Station, Texas 77845, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Putative nucleotide sugar dehydratase
A, B
356Campylobacter jejuniMutation(s): 0
UniProt
Find proteins for A0A0U3AP28 (Campylobacter jejuni)
Explore A0A0U3AP28
Go to UniProtKB:  A0A0U3AP28
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0U3AP28
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
YCX (Subject of Investigation/LOI)
Query on YCX

Download Ideal Coordinates CCD File
C [auth A],
E [auth B]
[[(2~{R},3~{S},4~{R},5~{R})-5-(4-azanyl-2-oxidanylidene-pyrimidin-1-yl)-3,4-bis(oxidanyl)oxolan-2-yl]methoxy-oxidanyl-phosphoryl] [(2~{R},3~{R},4~{R},5~{S})-2,3,4,5,6-pentakis(oxidanyl)hexyl] hydrogen phosphate
C15 H27 N3 O16 P2
WSJYSDVJOUCAAL-WZWGQWAVSA-N
PO4
Query on PO4

Download Ideal Coordinates CCD File
F [auth B]PHOSPHATE ION
O4 P
NBIIXXVUZAFLBC-UHFFFAOYSA-K
CL
Query on CL

Download Ideal Coordinates CCD File
D [auth A],
G [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
NA
Query on NA

Download Ideal Coordinates CCD File
H [auth B]SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.282
  • R-Value Work: 0.207
  • R-Value Observed: 0.211
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 54.76α = 90
b = 101.593β = 90
c = 133.304γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
SAINTdata reduction
SADABSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM134643
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesGM 139428

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-20
    Type: Initial release
  • Version 1.1: 2024-03-06
    Changes: Database references
  • Version 1.2: 2024-03-13
    Changes: Database references
