8UR1 | pdb_00008ur1

Crystal structure N-acetylneuraminate lyase (NanA) from Klebsiella aerogenes (pyruvate bound halide free active site)

PDB DOI: https://doi.org/10.2210/pdb8UR1/pdb

Classification: LIPID TRANSPORT
Organism(s): Klebsiella aerogenes KCTC 2190
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2023-10-25 Released: 2023-11-08
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.214 (Depositor), 0.217 (DCC)
R-Value Work:
0.183 (Depositor), 0.188 (DCC)
R-Value Observed:
0.184 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8UR1

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure N-acetylneuraminate lyase (NanA) from Klebsiella aerogenes (pyruvate bound halide free active site)

Lovell, S., Liu, L., Seibold, S., Mian, M.R.

To be published.

Macromolecule Content

Total Structure Weight: 34.99 kDa
Atom Count: 2,533
Modeled Residue Count: 296
Deposited Residue Count: 305
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
N-acetylneuraminate lyase	A	305	Klebsiella aerogenes KCTC 2190	Mutation(s): 1 Gene Names: nanA EC: 4.1.3.3
UniProt
Find proteins for A0A0H3FJT8 (Klebsiella aerogenes (strain ATCC 13048 / DSM 30053 / CCUG 1429 / JCM 1235 / KCTC 2190 / NBRC 13534 / NCIMB 10102 / NCTC 10006 / CDC 819-56)) Explore A0A0H3FJT8 Go to UniProtKB: A0A0H3FJT8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0H3FJT8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download:Ideal Coordinates CCD File SDF format, chain S [auth A] MOL2 format, chain S [auth A] mmCIF format, chain S [auth A]	S [auth A]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain S [auth A] Interactions & Density Focus chain S [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A]	J [auth A], K [auth A], L [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Interactions & Density Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain P [auth A] SDF format, chain O [auth A] SDF format, chain N [auth A] SDF format, chain M [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A]	M [auth A], N [auth A], O [auth A], P [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A]
NO3 Query on NO3 Download:Ideal Coordinates CCD File SDF format, chain R [auth A] SDF format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain Q [auth A] mmCIF format, chain R [auth A] mmCIF format, chain Q [auth A]	Q [auth A], R [auth A]	NITRATE ION N O₃ NHNBFGGVMKEFGY-UHFFFAOYSA-N		Interactions Focus chain Q [auth A] Focus chain R [auth A] Interactions & Density Focus chain Q [auth A] Focus chain R [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A]	F [auth A], G [auth A], H [auth A], I [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A], E [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
KPI Query on KPI	A	L-PEPTIDE LINKING	C₉ H₁₆ N₂ O₄		LYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.214 (Depositor), 0.217 (DCC)
R-Value Work: 0.183 (Depositor), 0.188 (DCC)
R-Value Observed: 0.184 (Depositor)

Diffraction Data:

Space Group: P 6₂ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 96.4	α = 90
b = 96.4	β = 90
c = 205.596	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-11-08

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036

Revision History (Full details and data files)

Version 1.0: 2023-11-08
Type: Initial release
Version 1.1: 2023-11-29
Changes: Data collection
