8TXL | pdb_00008txl

Nan Regulatory Protein full length mutant R148A

PDB DOI: https://doi.org/10.2210/pdb8TXL/pdb

Classification: TRANSCRIPTION
Organism(s): Streptococcus pneumoniae
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2023-08-23 Released: 2024-09-11
Deposition Author(s): Wood, D.M., Horne, C.R., Dobson, R.C.J.
Funding Organization(s): Royal Society of New Zealand, Ministry of Business, Innovation and Employment (New Zealand)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.82 Å
R-Value Free:
0.252 (Depositor), 0.258 (DCC)
R-Value Work:
0.210 (Depositor), 0.214 (DCC)
R-Value Observed:
0.212 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8TXL

This is version 1.0 of the entry. See complete history.

Literature

Structure of isomerase domain of the nan-regulatory protein (NanR) from Streptococcus pneumoniae

Wood, D.M., Dobson, R.C.J.

To be published.

Macromolecule Content

Total Structure Weight: 66.8 kDa
Atom Count: 4,745
Modeled Residue Count: 551
Deposited Residue Count: 566
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phosphosugar-binding transcriptional regulator	A, B	283	Streptococcus pneumoniae	Mutation(s): 1 Gene Names: ybbH_2
UniProt
Find proteins for A0A4M6CQT5 (Streptococcus pneumoniae) Explore A0A4M6CQT5 Go to UniProtKB: A0A4M6CQT5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A4M6CQT5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A], D [auth A]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A]	G [auth A], H [auth A], I [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A]
PO4 Query on PO4 Download:Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain T [auth B] SDF format, chain S [auth B] MOL2 format, chain K [auth A] MOL2 format, chain T [auth B] MOL2 format, chain S [auth B] mmCIF format, chain K [auth A] mmCIF format, chain T [auth B] mmCIF format, chain S [auth B]	K [auth A], S [auth B], T [auth B]	PHOSPHATE ION O₄ P NBIIXXVUZAFLBC-UHFFFAOYSA-K		Interactions Focus chain K [auth A] Focus chain S [auth B] Focus chain T [auth B] Interactions & Density Focus chain K [auth A] Focus chain S [auth B] Focus chain T [auth B]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain P [auth B] SDF format, chain O [auth B] SDF format, chain N [auth B] MOL2 format, chain P [auth B] MOL2 format, chain O [auth B] MOL2 format, chain N [auth B] mmCIF format, chain P [auth B] mmCIF format, chain O [auth B] mmCIF format, chain N [auth B]	N [auth B], O [auth B], P [auth B]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B] Interactions & Density Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain M [auth B] SDF format, chain F [auth A] MOL2 format, chain M [auth B] MOL2 format, chain F [auth A] mmCIF format, chain M [auth B] mmCIF format, chain F [auth A]	F [auth A], M [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain M [auth B] Interactions & Density Focus chain F [auth A] Focus chain M [auth B]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain L [auth B] SDF format, chain E [auth A] MOL2 format, chain L [auth B] MOL2 format, chain E [auth A] mmCIF format, chain L [auth B] mmCIF format, chain E [auth A]	E [auth A], L [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain L [auth B] Interactions & Density Focus chain E [auth A] Focus chain L [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain R [auth B] SDF format, chain Q [auth B] SDF format, chain J [auth A] MOL2 format, chain R [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain J [auth A] mmCIF format, chain R [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain J [auth A]	J [auth A], Q [auth B], R [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain J [auth A] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain J [auth A] Focus chain Q [auth B] Focus chain R [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.82 Å
R-Value Free: 0.252 (Depositor), 0.258 (DCC)
R-Value Work: 0.210 (Depositor), 0.214 (DCC)
R-Value Observed: 0.212 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.758	α = 90
b = 104.728	β = 90
c = 205.659	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-09-11

Deposition Author(s):

Funding Organization	Location	Grant Number
Royal Society of New Zealand	New Zealand	UOC1506
Ministry of Business, Innovation and Employment (New Zealand)	New Zealand	UOCX1706

Revision History (Full details and data files)

Version 1.0: 2024-09-11
Type: Initial release
