8TRI | pdb_00008tri

Crystal Structure of Mouse Cadherin-23 EC25-MAD28 F2894A

PDB DOI: https://doi.org/10.2210/pdb8TRI/pdb

Classification: CELL ADHESION
Organism(s): Mus musculus
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2023-08-09 Released: 2024-08-28
Deposition Author(s): Ashraf, Q., Sotomayor, M.
Funding Organization(s): National Institutes of Health/National Institute on Deafness and Other Communication Disorders (NIH/NIDCD)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.72 Å
R-Value Free:
0.229 (Depositor), 0.229 (DCC)
R-Value Work:
0.187 (Depositor), 0.192 (DCC)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8TRI

This is version 1.0 of the entry. See complete history.

Literature

Crystal Structure of Mouse Cadherin-23 EC25-MAD28 F2894A

Ashraf, Q., Sotomayor, M.

To be published.

Macromolecule Content

Total Structure Weight: 160.43 kDa
Atom Count: 10,517
Modeled Residue Count: 1,326
Deposited Residue Count: 1,422
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cadherin-23	A, B, C	474	Mus musculus	Mutation(s): 1 Gene Names: Cdh23
UniProt & NIH Common Fund Data Resources
Find proteins for Q99PF4 (Mus musculus) Explore Q99PF4 Go to UniProtKB: Q99PF4
IMPC: MGI:1890219
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q99PF4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CA (Subject of Investigation/LOI) Query on CA Download:Ideal Coordinates CCD File SDF format, chain U [auth C] SDF format, chain T [auth C] SDF format, chain S [auth C] SDF format, chain R [auth C] SDF format, chain Q [auth C] SDF format, chain P [auth C] SDF format, chain O [auth B] SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain U [auth C] MOL2 format, chain T [auth C] MOL2 format, chain S [auth C] MOL2 format, chain R [auth C] MOL2 format, chain Q [auth C] MOL2 format, chain P [auth C] MOL2 format, chain O [auth B] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain U [auth C] mmCIF format, chain T [auth C] mmCIF format, chain S [auth C] mmCIF format, chain R [auth C] mmCIF format, chain Q [auth C] mmCIF format, chain P [auth C] mmCIF format, chain O [auth B] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth B], K [auth B], L [auth B], M [auth B], N [auth B], O [auth B], P [auth C], Q [auth C], R [auth C], S [auth C], T [auth C], U [auth C]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain R [auth C] Focus chain S [auth C] Focus chain T [auth C] Focus chain U [auth C] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain R [auth C] Focus chain S [auth C] Focus chain T [auth C] Focus chain U [auth C]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 3.72 Å
R-Value Free: 0.229 (Depositor), 0.229 (DCC)
R-Value Work: 0.187 (Depositor), 0.192 (DCC)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 146.994	α = 90
b = 164.657	β = 90
c = 183.634	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-08-28

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute on Deafness and Other Communication Disorders (NIH/NIDCD)	United States	R01 DC015271

Revision History (Full details and data files)

Version 1.0: 2024-08-28
Type: Initial release
