8TQU

MPI51 bound to Mpro of SARS-CoV-2

• PDB DOI: https://doi.org/10.2210/pdb8TQU/pdb

• Classification: HYDROLASE
• Organism(s): Severe acute respiratory syndrome coronavirus 2, synthetic construct
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2023-08-08 Released: 2024-08-14
• Deposition Author(s): Blankenship, L.R., Liu, W.R.
• Funding Organization(s): Welch Foundation, National Institutes of Health/National Cancer Institute (NIH/NCI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free: 0.269
• R-Value Work: 0.235
• R-Value Observed: 0.236

Starting Model: experimental

Literature

MPI51 bound to SARS-CoV-2 Mpro

Blankenship, L.R., Liu, W.R.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 34.26 kDa
• Atom Count: 2,582
• Modelled Residue Count: 309
• Deposited Residue Count: 309
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3C-like proteinase nsp5	A	306	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.4.22.69
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
UAW247	B	3	synthetic construct	Mutation(s): 0

Biologically Interesting Molecules (External Reference) 1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_002393	B	UAW247	Peptide-like / Inhibitor

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free: 0.269
• R-Value Work: 0.235
• R-Value Observed: 0.236
• Space Group: I 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.552	α = 90
b = 81.096	β = 97.315
c = 86.908	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
PROTEUM PLUS	data reduction
Aimless	data scaling
PHENIX	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-08-14
Deposition Author(s): Blankenship, L.R., Liu, W.R.

---

Funding Organization	Location	Grant Number
Welch Foundation	United States	A-1715
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	R35GM145351

Revision History

• Version 1.0: 2024-08-14
  Type: Initial release
