8TLO

Crystal Structure Analysis of BCL11A in complex with DNA

• PDB DOI: https://doi.org/10.2210/pdb8TLO/pdb
• NAKB: 8TLO

• Classification: TRANSCRIPTION
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2023-07-27 Released: 2024-08-14
• Deposition Author(s): Seo, H.-S., Dhe-Paganon, S.
• Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.76 Å
• R-Value Free: 0.269
• R-Value Work: 0.252
• R-Value Observed: 0.253

Starting Model: experimental

Literature

Crystal Structure Analysis of BCL11A in complex with DNA

Seo, H.-S., Dhe-Paganon, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 24.6 kDa
• Atom Count: 1,445
• Modelled Residue Count: 123
• Deposited Residue Count: 148
• Unique protein chains: 1
• Unique nucleic acid chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
B-cell lymphoma/leukemia 11A	A	110	Homo sapiens	Mutation(s): 0  Gene Names: BCL11A, CTIP1, EVI9, KIAA1809, ZNF856
UniProt & NIH Common Fund Data Resources
Find proteins for Q9H165 (Homo sapiens) Explore Q9H165  Go to UniProtKB:  Q9H165
PHAROS:  Q9H165 GTEx:  ENSG00000119866

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(P*CP*GP*AP*CP*CP*GP*CP*AP*TP*TP*GP*GP*TP*CP*AP*AP*GP*CP*G)-3')	B	19	Homo sapiens

Entity ID: 3
Molecule	Chains	Length	Organism	Image
DNA (5'-D(P*GP*CP*TP*TP*GP*AP*CP*CP*AP*AP*TP*GP*CP*GP*GP*TP*CP*GP*C)-3')	C	19	Homo sapiens

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	D [auth A], E [auth A], F [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.76 Å
• R-Value Free: 0.269
• R-Value Work: 0.252
• R-Value Observed: 0.253
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 116.74	α = 90
b = 60.87	β = 108.2
c = 78.35	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data scaling
XDS	data reduction
PHENIX	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-08-14
Deposition Author(s): Seo, H.-S., Dhe-Paganon, S.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	--

Revision History

• Version 1.0: 2024-08-14
  Type: Initial release
