Tuning chemical DNA ligation within DNA crystals and protein-DNA co-crystals
Orun, A.R., Slaughter, C.K., Shields, E.T., Vajapayajula, A., Jones, S., Shrestha, R., Snow, C.D.(2024) ACS Nanosci Au
Experimental Data Snapshot
Starting Model: experimental
View more details
wwPDB Validation   3D Report Full Report
(2024) ACS Nanosci Au
Entity ID: 3 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Replication initiation protein | 263 | Escherichia coli K-12 | Mutation(s): 1  Gene Names: repE, E, rep, ECOK12F045 | ![]() | |
UniProt | |||||
Find proteins for P03856 (Escherichia coli (strain K12)) Explore P03856  Go to UniProtKB:  P03856 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | P03856 | ||||
Sequence AnnotationsExpand | |||||
|
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Length | Organism | Image | |
DNA (5'-D(CP*CP*CP*GP*GP*AP*CP*CP*TP*GP*TP*GP*AP*CP*AP*AP*AP*TP*TP*GP*CP*CP*CP*TP*CP*AP*GP*AP*CP*GP*GP*A)-3')| | 32 | Escherichia coli | ![]() | ||
Sequence AnnotationsExpand | |||||
|
Entity ID: 2 | |||||
---|---|---|---|---|---|
Molecule | Chains | Length | Organism | Image | |
DNA (5'-D(GP*GP*CP*CP*GP*TP*CP*TP*GP*AP*GP*GP*GP*CP*AP*AP*TP*TP*TP*GP*TP*CP*AP*CP*AP*GP*GP*TP*CP*CP*GP*A)-3') | 32 | Escherichia coli | ![]() | ||
Sequence AnnotationsExpand | |||||
|
Ligands 1 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
MG Query on MG | D [auth C] | MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 72.946 | α = 90 |
b = 133.506 | β = 90 |
c = 134.06 | γ = 90 |
Software Name | Purpose |
---|---|
PHENIX | refinement |
Coot | model building |
XDS | data reduction |
XSCALE | data scaling |
SCALA | data scaling |
PHASER | phasing |
Funding Organization | Location | Grant Number |
---|---|---|
National Science Foundation (NSF, United States) | United States | 2003748 |
