Conformational dynamics of the Plasmodium falciparum M1 aminopeptidase.
Webb, C.T., McGowan, S., Yang, W., Drinkwater, N.To be published.
Experimental Data Snapshot
Starting Model: experimental
View more details
wwPDB Validation   3D Report Full Report
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Aminopeptidase N | 898 | Plasmodium falciparum | Mutation(s): 1  Gene Names: M1AAP, MAL13P1.56, PF3D7_1311800 EC: 3.4.11 | ![]() | |
UniProt | |||||
Find proteins for O96935 (Plasmodium falciparum (isolate 3D7)) Explore O96935  Go to UniProtKB:  O96935 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | O96935 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 3 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
GOL Query on GOL | C [auth A], D [auth A], E [auth A], F [auth A], G [auth A] | GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N | |||
ZN (Subject of Investigation/LOI) Query on ZN | B [auth A] | ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N | |||
MG Query on MG | H [auth A], I [auth A] | MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N |
Length ( Å ) | Angle ( ˚ ) |
---|---|
a = 75.01 | α = 90 |
b = 108.93 | β = 90 |
c = 117.63 | γ = 90 |
Software Name | Purpose |
---|---|
PHENIX | refinement |
Aimless | data scaling |
XDS | data reduction |
PHASER | phasing |
Funding Organization | Location | Grant Number |
---|---|---|
National Health and Medical Research Council (NHMRC, Australia) | Australia | -- |
