8T4I | pdb_00008t4i

Transporter associated with antigen processing (TAP) bound to the 7-mer peptide RRYSTEL


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 5.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8T4I

This is version 1.2 of the entry. See complete history

Literature

Principles of peptide selection by the transporter associated with antigen processing.

Lee, J.Oldham, M.L.Manon, V.Chen, J.

(2024) Proc Natl Acad Sci U S A 121: e2320879121-e2320879121

  • DOI: https://doi.org/10.1073/pnas.2320879121
  • Primary Citation Related Structures:
    8T46, 8T4E, 8T4F, 8T4G, 8T4H, 8T4I, 8T4J

  • PubMed Abstract:

    Our ability to fight pathogens relies on major histocompatibility complex class I (MHC-I) molecules presenting diverse antigens on the surface of diseased cells. The transporter associated with antigen processing (TAP) transports nearly the entire repertoire of antigenic peptides into the endoplasmic reticulum for MHC-I loading. How TAP transports peptides specific for MHC-I is unclear. In this study, we used cryo-EM to determine a series of structures of human TAP, both in the absence and presence of peptides with various sequences and lengths. The structures revealed that peptides of eight or nine residues in length bind in a similarly extended conformation, despite having little sequence overlap. We also identified two peptide-anchoring pockets on either side of the transmembrane cavity, each engaging one end of a peptide with primarily main chain atoms. Occupation of both pockets results in a global conformational change in TAP, bringing the two halves of the transporter closer together to prime it for isomerization and ATP hydrolysis. Shorter peptides are able to bind to each pocket separately but are not long enough to bridge the cavity to bind to both simultaneously. Mutations that disrupt hydrogen bonds with the N and C termini of peptides almost abolish MHC-I surface expression. Our findings reveal that TAP functions as a molecular caliper that selects peptides according to length rather than sequence, providing antigen diversity for MHC-I presentation.


  • Organizational Affiliation
    • Laboratory of Membrane Biophysics and Biology, The Rockefeller University, New York, NY 10065.

Macromolecule Content

  • Total Structure Weight: 158.62 kDa
  • Atom Count: 7,809
  • Modeled Residue Count: 1,099
  • Deposited Residue Count: 1,448
  • Unique protein chains: 3

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Antigen peptide transporter 1748Homo sapiensMutation(s): 0
Gene Names: TAP1ABCB2PSF1RING4Y3
EC: 7.4.2.14
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q03518 (Homo sapiens)
Explore Q03518
Go to UniProtKB:  Q03518
PHAROS:  Q03518
GTEx:  ENSG00000168394
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03518
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Antigen peptide transporter 2686Homo sapiensMutation(s): 0
Gene Names: TAP2ABCB3PSF2RING11Y1
EC: 7.4.2.14
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q03519 (Homo sapiens)
Explore Q03519
Go to UniProtKB:  Q03519
PHAROS:  Q03519
GTEx:  ENSG00000204267
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03519
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
Synthetic 7-mer peptide
C, D
7synthetic constructMutation(s): 0

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 5.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
RECONSTRUCTIONcryoSPARC4

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Howard Hughes Medical Institute (HHMI)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2024-06-19
    Type: Initial release
  • Version 1.1: 2025-01-08
    Changes: Data collection, Database references, Structure summary
  • Version 1.2: 2025-05-14
    Changes: Data collection
