8RUY | pdb_00008ruy

Structure of IFTA and IFTB in Retrograde Intraflagellar transport trains


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 15.4 Å
  • Aggregation State: CELL
  • Reconstruction Method: SUBTOMOGRAM AVERAGING

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Extensive structural rearrangement of intraflagellar transport trains underpins bidirectional cargo transport.

Lacey, S.E.Graziadei, A.Pigino, G.

(2024) Cell 187: 4621-4636.e18

  • DOI: https://doi.org/10.1016/j.cell.2024.06.041
  • Primary Citation of Related Structures:
    8RUY

  • PubMed Abstract:

    Bidirectional transport in cilia is carried out by polymers of the IFTA and IFTB protein complexes, called anterograde and retrograde intraflagellar transport (IFT) trains. Anterograde trains deliver cargoes from the cell to the cilium tip, then convert into retrograde trains for cargo export. We set out to understand how the IFT complexes can perform these two directly opposing roles before and after conversion. We use cryoelectron tomography and in situ cross-linking mass spectrometry to determine the structure of retrograde IFT trains and compare it with the known structure of anterograde trains. The retrograde train is a 2-fold symmetric polymer organized around a central thread of IFTA complexes. We conclude that anterograde-to-retrograde remodeling involves global rearrangements of the IFTA/B complexes and requires complete disassembly of the anterograde train. Finally, we describe how conformational changes to cargo-binding sites facilitate unidirectional cargo transport in a bidirectional system.


  • Organizational Affiliation
    • Human Technopole, Milan 20157, Italy.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 1441,367Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A9XPA7 (Chlamydomonas reinhardtii)
Explore A9XPA7
Go to UniProtKB:  A9XPA7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA9XPA7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport particle protein 1401,409Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A0A2K3DGM1 (Chlamydomonas reinhardtii)
Explore A0A2K3DGM1
Go to UniProtKB:  A0A2K3DGM1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2K3DGM1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Osm-6-like proteinC [auth H],
N [auth h]
454Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for Q946G4 (Chlamydomonas reinhardtii)
Explore Q946G4
Go to UniProtKB:  Q946G4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ946G4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 80D [auth J],
P [auth j]
765Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A5Z0S9 (Chlamydomonas reinhardtii)
Explore A5Z0S9
Go to UniProtKB:  A5Z0S9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA5Z0S9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
IFT54E [auth K],
Q [auth k]
510Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A8JBY2 (Chlamydomonas reinhardtii)
Explore A8JBY2
Go to UniProtKB:  A8JBY2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8JBY2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport particle protein IFT20F [auth L],
R [auth l]
135Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for Q8LLV9 (Chlamydomonas reinhardtii)
Explore Q8LLV9
Go to UniProtKB:  Q8LLV9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8LLV9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Clusterin-associated protein 1G [auth N],
S [auth n]
443Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A0A2K3CQB1 (Chlamydomonas reinhardtii)
Explore A0A2K3CQB1
Go to UniProtKB:  A0A2K3CQB1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2K3CQB1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 74H [auth O]641Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for Q6RCE1 (Chlamydomonas reinhardtii)
Explore Q6RCE1
Go to UniProtKB:  Q6RCE1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6RCE1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 81I [auth P]683Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for Q68RJ5 (Chlamydomonas reinhardtii)
Explore Q68RJ5
Go to UniProtKB:  Q68RJ5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ68RJ5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 27J [auth Q]204Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A8HN58 (Chlamydomonas reinhardtii)
Explore A8HN58
Go to UniProtKB:  A8HN58
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8HN58
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 25K [auth R]189Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for B8LIX8 (Chlamydomonas reinhardtii)
Explore B8LIX8
Go to UniProtKB:  B8LIX8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupB8LIX8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 46L [auth S],
T [auth s]
344Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A2T2X4 (Chlamydomonas reinhardtii)
Explore A2T2X4
Go to UniProtKB:  A2T2X4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA2T2X4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 22M [auth T]192Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A8HME3 (Chlamydomonas reinhardtii)
Explore A8HME3
Go to UniProtKB:  A8HME3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8HME3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 172O [auth i],
Z [auth I]
1,755Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for Q5DM57 (Chlamydomonas reinhardtii)
Explore Q5DM57
Go to UniProtKB:  Q5DM57
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ5DM57
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 122 homologU [auth C]1,239Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for H9CTG6 (Chlamydomonas reinhardtii)
Explore H9CTG6
Go to UniProtKB:  H9CTG6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupH9CTG6
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 121V [auth D]1,224Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A8JFR3 (Chlamydomonas reinhardtii)
Explore A8JFR3
Go to UniProtKB:  A8JFR3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8JFR3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 139W [auth E]1,355Chlamydomonas reinhardtiiMutation(s): 1
UniProt
Find proteins for A0A2K3DN83 (Chlamydomonas reinhardtii)
Explore A0A2K3DN83
Go to UniProtKB:  A0A2K3DN83
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2K3DN83
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChains Sequence LengthOrganismDetailsImage
IFT88BA [auth f],
X [auth F]
782Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A8JCJ2 (Chlamydomonas reinhardtii)
Explore A8JCJ2
Go to UniProtKB:  A8JCJ2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8JCJ2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 19
MoleculeChains Sequence LengthOrganismDetailsImage
IFT70CA [auth g],
Y [auth G]
647Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for A8ITN7 (Chlamydomonas reinhardtii)
Explore A8ITN7
Go to UniProtKB:  A8ITN7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA8ITN7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 20
MoleculeChains Sequence LengthOrganismDetailsImage
Intraflagellar transport protein 57AA [auth M],
DA [auth m]
469Chlamydomonas reinhardtiiMutation(s): 0
UniProt
Find proteins for Q2XQY7 (Chlamydomonas reinhardtii)
Explore Q2XQY7
Go to UniProtKB:  Q2XQY7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2XQY7
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 15.4 Å
  • Aggregation State: CELL
  • Reconstruction Method: SUBTOMOGRAM AVERAGING
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1.3

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Research Council (ERC)European Union--
Other government--

Revision History  (Full details and data files)

  • Version 1.0: 2024-07-24
    Type: Initial release
  • Version 1.1: 2024-11-06
    Changes: Data collection, Structure summary
  • Version 1.2: 2025-08-06
    Changes: Data collection, Database references
