8RJZ

Crystal structure of SARS-CoV-2 main protease (MPro) in complex with the non-covalent inhibitor GUE-3801 (compound 80 in publication)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.195
  • R-Value Observed: 0.196

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Macrocyclic Azapeptide Nitriles: Structure-Based Discovery of Potent SARS-CoV-2 Main Protease Inhibitors as Antiviral Drugs.

Breidenbach, J.Voget, R.Si, Y.Hingst, A.Claff, T.Sylvester, K.Wolf, V.Krasniqi, V.Useini, A.Strater, N.Ogura, Y.Kawaguchi, A.Muller, C.E.Gutschow, M.

(2024) J Med Chem 67: 8757-8790

  • DOI: https://doi.org/10.1021/acs.jmedchem.4c00053
  • Primary Citation of Related Structures:
    8RJV, 8RJY, 8RJZ

  • PubMed Abstract:

    Given the crucial role of the main protease (M pro ) in the replication cycle of SARS-CoV-2, this viral cysteine protease constitutes a high-profile drug target. We investigated peptidomimetic azapeptide nitriles as auspicious, irreversibly acting inhibitors of M pro . Our systematic approach combined an M pro active-site scanning by combinatorially assembled azanitriles with structure-based design. Encouraged by the bioactive conformation of open-chain inhibitors, we conceptualized the novel chemotype of macrocyclic azanitriles whose binding mode was elucidated by cocrystallization. This strategy provided a favorable entropic contribution to target binding and resulted in the development of the extraordinarily potent M pro inhibitor 84 with an IC 50 value of 3.23 nM and a second-order rate constant of inactivation, k inac / K i , of 448,000 M -1 s -1 . The open-chain M pro inhibitor 58 , along with the macrocyclic compounds 83 and 84 , a broad-spectrum anticoronaviral agent, demonstrated the highest antiviral activity with EC 50 values in the single-digit micromolar range. Our findings are expected to promote the future development of peptidomimetic M pro inhibitors as anti-SARS-CoV-2 agents.


  • Organizational Affiliation

    Pharmaceutical Institute, Pharmaceutical & Medicinal Chemistry, University of Bonn, An der Immenburg 4, 53121 Bonn, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
3C-like proteinase nsp5
A, B
306Severe acute respiratory syndrome coronavirus 2Mutation(s): 0
Gene Names: rep1a-1b
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2)
Explore P0DTD1
Go to UniProtKB:  P0DTD1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0DTD1
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1H1I (Subject of Investigation/LOI)
Query on A1H1I

Download Ideal Coordinates CCD File
C [auth A],
G [auth B]
(7~{S})-6-[2-[2,4-bis(chloranyl)phenoxy]ethanoyl]-14-fluoranyl-10-(iminomethyl)-9-methyl-7-(phenylmethyl)-2-oxa-6,9,10-triazabicyclo[10.4.0]hexadeca-1(12),13,15-trien-8-one
C29 H29 Cl2 F N4 O4
NQCXTIOJRFEOCJ-VWLOTQADSA-N
B3P
Query on B3P

Download Ideal Coordinates CCD File
D [auth A],
H [auth B]
2-[3-(2-HYDROXY-1,1-DIHYDROXYMETHYL-ETHYLAMINO)-PROPYLAMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C11 H26 N2 O6
HHKZCCWKTZRCCL-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
E [auth A],
F [auth A]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free: 0.234
  • R-Value Work: 0.195
  • R-Value Observed: 0.196
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 67.883α = 90
b = 88.574β = 90
c = 102.166γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
STARANISOdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Volkswagen FoundationGermany9A894
Volkswagen FoundationGermany9A850
German Research Foundation (DFG)GermanyGRK2873 (494832089)

Revision History  (Full details and data files)

  • Version 1.0: 2024-05-29
    Type: Initial release
  • Version 1.1: 2024-06-19
    Changes: Database references, Source and taxonomy, Structure summary
