8RJ5 | pdb_00008rj5

P1-15 T-cell Receptor bound to HLA A*2402-NF9 pMHC complex

• PDB DOI: https://doi.org/10.2210/pdb8RJ5/pdb

• Classification: IMMUNE SYSTEM
• Organism(s): Homo sapiens, Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2023-12-20 Released: 2025-01-01
• Deposition Author(s): Wall, A., Sewell, A.K., Motozono, C., Rizkallah, P.J., Fuller, A.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.02 Å
• R-Value Free:
  0.260 (Depositor), 0.258 (DCC)
• R-Value Work:
  0.220 (Depositor), 0.221 (DCC)
• R-Value Observed:
  0.222 (Depositor)

Literature

NF9 T-cell Receptor bound to HLA A*2402-NF9 pMHC complex (Paper Pending)

Motozono, C., Wall, A., Sewell, A.K., Rizkallah, P.J., Fuller, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 5-mer - A1B1C1D1E1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: surface plasmon resonance

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 5-mer - A1B1C1D1E1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 190.87 kDa
• Atom Count: 13,408
• Modeled Residue Count: 1,668
• Deposited Residue Count: 1,670
• Unique protein chains: 5

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MHC class I antigen	A, F	277	Homo sapiens	Mutation(s): 0  Gene Names: HLA-A
UniProt
Find proteins for A0A5H2UYS3 (Homo sapiens) Explore A0A5H2UYS3  Go to UniProtKB:  A0A5H2UYS3

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-2-microglobulin	B, G	100	Homo sapiens	Mutation(s): 0  Gene Names: B2M, CDABP0092, HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens) Explore P61769  Go to UniProtKB:  P61769
PHAROS:  P61769 GTEx:  ENSG00000166710

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike protein S1	C, H	9	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2  Go to UniProtKB:  P0DTC2

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
P1-15 T-cell Receptor Alpha Chain	D, I	204	Homo sapiens	Mutation(s): 0

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
P1-15 T-cell Receptor Beta Chain	E, J	245	Homo sapiens	Mutation(s): 0

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.02 Å
• R-Value Free:  0.260 (Depositor), 0.258 (DCC)
• R-Value Work:  0.220 (Depositor), 0.221 (DCC)
• R-Value Observed: 0.222 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 200.439	α = 90
b = 200.439	β = 90
c = 156.272	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
DIALS	data scaling
DIALS	data reduction
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2025-01-01
Deposition Author(s): Wall, A., Sewell, A.K., Motozono, C., Rizkallah, P.J., Fuller, A.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-01-01
  Type: Initial release
