8R28 | pdb_00008r28

Crystal structure of Amacstatin-1, a cystatin from the hard tick Amblyomma maculatum

PDB DOI: https://doi.org/10.2210/pdb8R28/pdb

Classification: PROTEIN BINDING
Organism(s): Amblyomma maculatum
Expression System: Komagataella pastoris
Mutation(s): No

Deposited: 2023-11-03 Released: 2024-11-13
Deposition Author(s): Busa, M., Mares, M.
Funding Organization(s): Czech Academy of Sciences

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.81 Å
R-Value Free:
0.202 (Depositor), 0.204 (DCC)
R-Value Work:
0.161 (Depositor), 0.162 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8R28

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of Amacstatin-1, a cystatin from the hard tick Amblyomma maculatum

Busa, M., Mares, M.

To be published.

Macromolecule Content

Total Structure Weight: 13.48 kDa
Atom Count: 975
Modeled Residue Count: 103
Deposited Residue Count: 121
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cystatin domain-containing protein	A	121	Amblyomma maculatum	Mutation(s): 0
UniProt
Find proteins for G3MPE6 (Amblyomma maculatum) Explore G3MPE6 Go to UniProtKB: G3MPE6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	G3MPE6
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.81 Å
R-Value Free: 0.202 (Depositor), 0.204 (DCC)
R-Value Work: 0.161 (Depositor), 0.162 (DCC)

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 98.411	α = 90
b = 98.411	β = 90
c = 27.579	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-11-13

Deposition Author(s):

Funding Organization	Location	Grant Number
Czech Academy of Sciences	Czech Republic	--

Revision History (Full details and data files)

Version 1.0: 2024-11-13
Type: Initial release
