8QSM | pdb_00008qsm

Cryo-EM structure of human SLC15A4 monomer in outward open state in LMNG

PDB DOI: https://doi.org/10.2210/pdb8QSM/pdb
EM Map EMD-18636: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): Yes
Membrane Protein: Yes PDBTM MemProtMD

Deposited: 2023-10-10 Released: 2023-10-25
Deposition Author(s): Rehan, S., Matsuoka, R., Jazayeri, A., Duerr, K.L.
Funding Organization(s): Other private

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.69 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8QSM

This is version 1.1 of the entry. See complete history.

Literature

Cryo-EM structure of human SLC15A4 monomer in outward open state in LMNG

Rehan, S., Matsuoka, R., Jazayeri, A., Duerr, K.L.

To be published.

Macromolecule Content

Total Structure Weight: 62 kDa
Atom Count: 3,579
Modeled Residue Count: 464
Deposited Residue Count: 577
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Solute carrier family 15 member 4	A	577	Homo sapiens	Mutation(s): 2 Gene Names: SLC15A4 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N697 (Homo sapiens) Explore Q8N697 Go to UniProtKB: Q8N697
PHAROS: Q8N697 GTEx: ENSG00000139370
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8N697
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.69 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-10-25

Deposition Author(s):

Funding Organization	Location	Grant Number
Other private		--

Revision History (Full details and data files)

Version 1.0: 2023-10-25
Type: Initial release
Version 1.1: 2025-07-09
Changes: Data collection, Structure summary
