8QRZ | pdb_00008qrz

Microbacterium testaceum C-glucosyl deglycosidase (CGD), wild type

PDB DOI: https://doi.org/10.2210/pdb8QRZ/pdb

Classification: LYASE
Organism(s): Microbacterium testaceum
Expression System: Escherichia coli B
Mutation(s): No

Deposited: 2023-10-09 Released: 2025-04-23
Deposition Author(s): Furlanetto, V., Kalyani, D.C., Divne, C.
Funding Organization(s): Other government, Other private

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.290 (Depositor), 0.286 (DCC)
R-Value Work:
0.236 (Depositor), 0.236 (DCC)
R-Value Observed:
0.237 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8QRZ

This is version 1.0 of the entry. See complete history.

Literature

Microbacterium testaceum C-glucosyl deglycosidase (CGD), wild type

Furlanetto, V., Kalyani, D.C., Srivastava, V., Hallberg, B.M., Ezcurra, I., Divne, C.

To be published.

Macromolecule Content

Total Structure Weight: 195.41 kDa
Atom Count: 14,165
Modeled Residue Count: 1,740
Deposited Residue Count: 1,740
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sugar phosphate isomerase	A, B, C, D	435	Microbacterium testaceum	Mutation(s): 0 Gene Names: NS220_14145
UniProt
Find proteins for A0A147EV52 (Microbacterium testaceum) Explore A0A147EV52 Go to UniProtKB: A0A147EV52
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A147EV52
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
RB (Subject of Investigation/LOI) Query on RB Download:Ideal Coordinates CCD File SDF format, chain H [auth D] SDF format, chain G [auth C] SDF format, chain F [auth B] SDF format, chain E [auth A] MOL2 format, chain H [auth D] MOL2 format, chain G [auth C] MOL2 format, chain F [auth B] MOL2 format, chain E [auth A] mmCIF format, chain H [auth D] mmCIF format, chain G [auth C] mmCIF format, chain F [auth B] mmCIF format, chain E [auth A]	E [auth A], F [auth B], G [auth C], H [auth D]	RUBIDIUM ION Rb NCCSSGKUIKYAJD-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth B] Focus chain G [auth C] Focus chain H [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.290 (Depositor), 0.286 (DCC)
R-Value Work: 0.236 (Depositor), 0.236 (DCC)
R-Value Observed: 0.237 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 78.22	α = 90.17
b = 80.41	β = 94.39
c = 82.96	γ = 106.58

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XDS	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-04-23

Deposition Author(s):

Funding Organization	Location	Grant Number
Other government	Sweden	Formas 2017-00983
Other private	Sweden	Oscar and Lili Lamm Memorial Foundation DO2017-0020
Other government	Sweden	VR 2017-03877

Revision History (Full details and data files)

Version 1.0: 2025-04-23
Type: Initial release
