8QCZ | pdb_00008qcz

Cryo-EM structure of the outward-facing heme-bound FLVCR2

PDB DOI: https://doi.org/10.2210/pdb8QCZ/pdb
EM Map EMD-18338: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No
Membrane Protein: Yes MemProtMD

Deposited: 2023-08-28 Released: 2024-09-11
Deposition Author(s): Weng, T.-H., Wu, D., Safarian, S.
Funding Organization(s): Max Planck Society

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.10 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8QCZ

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of the outward-facing heme-bound FLVCR2

Weng, T.-H., Wu, D., Safarian, S.

To be published.

Macromolecule Content

Total Structure Weight: 58.89 kDa
Atom Count: 3,316
Modeled Residue Count: 421
Deposited Residue Count: 534
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Heme transporter FLVCR2	A	534	Homo sapiens	Mutation(s): 0 Gene Names: FLVCR2, C14orf58 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UPI3 (Homo sapiens) Explore Q9UPI3 Go to UniProtKB: Q9UPI3
PHAROS: Q9UPI3 GTEx: ENSG00000119686
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9UPI3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HEM (Subject of Investigation/LOI) Query on HEM Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	PROTOPORPHYRIN IX CONTAINING FE C₃₄ H₃₂ Fe N₄ O₄ KABFMIBPWCXCRK-RGGAHWMASA-L		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.10 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC
MODEL REFINEMENT	PHENIX	1.18

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-09-11

Deposition Author(s):

Funding Organization	Location	Grant Number
Max Planck Society	Germany	--

Revision History (Full details and data files)

Version 1.0: 2024-09-11
Type: Initial release
