8PKJ

Cryo-EM structure of the nucleosome containing Nr5a2 motif at SHL+5.5


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Nucleosome-bound NR5A2 structure reveals pioneer factor mechanism by DNA minor groove anchor competition.

Kobayashi, W.Sappler, A.H.Bollschweiler, D.Kummecke, M.Basquin, J.Arslantas, E.N.Ruangroengkulrith, S.Hornberger, R.Duderstadt, K.Tachibana, K.

(2024) Nat Struct Mol Biol 31: 757-766

  • DOI: https://doi.org/10.1038/s41594-024-01239-0
  • Primary Citation of Related Structures:
    8PKI, 8PKJ

  • PubMed Abstract:

    Gene expression during natural and induced reprogramming is controlled by pioneer transcription factors that initiate transcription from closed chromatin. Nr5a2 is a key pioneer factor that regulates zygotic genome activation in totipotent embryos, pluripotency in embryonic stem cells and metabolism in adult tissues, but the mechanism of its pioneer activity remains poorly understood. Here, we present a cryo-electron microscopy structure of human NR5A2 bound to a nucleosome. The structure shows that the conserved carboxy-terminal extension (CTE) loop of the NR5A2 DNA-binding domain competes with a DNA minor groove anchor of the nucleosome and releases entry-exit site DNA. Mutational analysis showed that NR5A2 D159 of the CTE is dispensable for DNA binding but required for stable nucleosome association and persistent DNA 'unwrapping'. These findings suggest that NR5A2 belongs to an emerging class of pioneer factors that can use DNA minor groove anchor competition to destabilize nucleosomes and facilitate gene expression during reprogramming.


  • Organizational Affiliation

    Department of Totipotency, Max Planck Institute of Biochemistry (MPIB), Munich, Germany.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H3 (Fragment)
A, E
136Mus musculusMutation(s): 0
Gene Names: SERLUN_R04475
UniProt
Find proteins for P84244 (Mus musculus)
Explore P84244
Go to UniProtKB:  P84244
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP84244
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H4
B, F
103Mus musculusMutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P62806 (Mus musculus)
Explore P62806
Go to UniProtKB:  P62806
IMPC:  MGI:2448443
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62806
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2A
C, G
130Mus musculusMutation(s): 0
Gene Names: Hist1h2ad
UniProt
Find proteins for C0HKE1 (Mus musculus)
Explore C0HKE1
Go to UniProtKB:  C0HKE1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupC0HKE1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Histone H2B
D, H
126Mus musculusMutation(s): 0
Gene Names: CR201_G0046179
UniProt
Find proteins for Q6ZWY9 (Mus musculus)
Explore Q6ZWY9
Go to UniProtKB:  Q6ZWY9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ZWY9
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains LengthOrganismImage
DNA153synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains LengthOrganismImage
DNA153synthetic construct
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.50 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Max Planck SocietyGermany--
European Research Council (ERC)European UnionERC-CoG-818556 TotipotentZygotChrom

Revision History  (Full details and data files)

  • Version 1.0: 2024-02-28
    Type: Initial release
  • Version 1.1: 2024-03-06
    Changes: Database references
  • Version 1.2: 2024-05-29
    Changes: Database references
