Rho P167L-ATPgS-Psu complex II
Gjorgjevikj, D., Wahl, M.C., Hilal, T., Loll, B.To be published.
Experimental Data Snapshot
Starting Models: experimental
View more details
wwPDB Validation   3D Report Full Report
Entity ID: 1 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Transcription termination factor Rho | 419 | Escherichia coli | Mutation(s): 1  Gene Names: rho, nitA, psuA, rnsC, sbaA, tsu, b3783, JW3756 EC: 3.6.4 | ![]() | |
UniProt | |||||
Find proteins for P0AG30 (Escherichia coli (strain K12)) Explore P0AG30  Go to UniProtKB:  P0AG30 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | P0AG30 | ||||
Sequence AnnotationsExpand | |||||
|
Entity ID: 2 | |||||
---|---|---|---|---|---|
Molecule | Chains | Sequence Length | Organism | Details | Image |
Polarity suppression protein | 190 | Enterobacteria phage P4 | Mutation(s): 0  Gene Names: psu | ![]() | |
UniProt | |||||
Find proteins for P05460 (Enterobacteria phage P4) Explore P05460  Go to UniProtKB:  P05460 | |||||
Entity Groups   | |||||
Sequence Clusters | 30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity | ||||
UniProt Group | P05460 | ||||
Sequence AnnotationsExpand | |||||
|
Ligands 2 Unique | |||||
---|---|---|---|---|---|
ID | Chains | Name / Formula / InChI Key | 2D Diagram | 3D Interactions | |
AGS Query on AGS | BA [auth D] DA [auth E] FA [auth F] HA [auth G] JA [auth I] | PHOSPHOTHIOPHOSPHORIC ACID-ADENYLATE ESTER C10 H16 N5 O12 P3 S NLTUCYMLOPLUHL-KQYNXXCUSA-N | |||
MG Query on MG | AA [auth C] CA [auth D] EA [auth E] GA [auth F] IA [auth G] | MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N |
Task | Software Package | Version |
---|---|---|
MODEL REFINEMENT | PHENIX | 1.20_4459 |
RECONSTRUCTION | cryoSPARC | v3.3.0 |
Funding Organization | Location | Grant Number |
---|---|---|
German Research Foundation (DFG) | Germany | RTG 2473-1 |
