8K4N | pdb_00008k4n

Structure of GPR34-Gi complex

• PDB DOI: https://doi.org/10.2210/pdb8K4N/pdb
• EM Map EMD-36887: EMDB EMDataResource

• Classification: MEMBRANE PROTEIN
• Organism(s): Homo sapiens, synthetic construct
• Expression System: Spodoptera frugiperda, Trichoplusia ni
• Mutation(s): Yes
• Membrane Protein: Yes  PDBTM


• Deposited: 2023-07-20 Released: 2023-10-25
• Deposition Author(s): Wong, T.S., Zeng, Z.C., Xiong, T.T., Gan, S.Y., He, G.D., Du, Y.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.83 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Cryo-EM structure of GPR34-Gi complex

Wong, T.S., Zeng, Z.C., Xiong, T.T.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 5-mer - A1B1C1D1E1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 142.27 kDa
• Atom Count: 8,656
• Modeled Residue Count: 1,117
• Deposited Residue Count: 1,268
• Unique protein chains: 5

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(i) subunit alpha-1	A	354	Homo sapiens	Mutation(s): 2  Gene Names: GNAI1 EC: 3.6.5 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P63096 (Homo sapiens) Explore P63096  Go to UniProtKB:  P63096
PHAROS:  P63096 GTEx:  ENSG00000127955

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1	B	336	Homo sapiens	Mutation(s): 0  Gene Names: GNB1
UniProt & NIH Common Fund Data Resources
Find proteins for P62873 (Homo sapiens) Explore P62873  Go to UniProtKB:  P62873
PHAROS:  P62873 GTEx:  ENSG00000078369

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2	C	53	Homo sapiens	Mutation(s): 0  Gene Names: GNG2 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P59768 (Homo sapiens) Explore P59768  Go to UniProtKB:  P59768
PHAROS:  P59768 GTEx:  ENSG00000186469

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
scFv16	D [auth E]	246	synthetic construct	Mutation(s): 0

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable G-protein coupled receptor 34	E [auth D]	279	Homo sapiens	Mutation(s): 0  Gene Names: GPR34 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UPC5 (Homo sapiens) Explore Q9UPC5  Go to UniProtKB:  Q9UPC5
PHAROS:  Q9UPC5 GTEx:  ENSG00000171659

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
VF0	F [auth D]	(2R)-2-azanyl-3-[oxidanyl-[(2R)-2-oxidanyl-3-tetradec-9-enoyloxy-propoxy]phosphoryl]oxy-propanoic acid C20 H38 N O9 P NPKANCOBLRPFQN-QZTJIDSGSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.83 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2023-10-25
Deposition Author(s): Wong, T.S., Zeng, Z.C., Xiong, T.T., Gan, S.Y., He, G.D., Du, Y.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-10-25
  Type: Initial release

• Version 1.1: 2024-10-23
  Changes: Data collection, Structure summary
• Version 1.2: 2025-07-02
  Changes: Data collection
