8K25

Structure of Cas1-Cas2-dsDNA complex

Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history.


Literature

Structure of Cas1-Cas2 complex bound dsDNA

Zhang, L.X., Feng, Y.

To be published.

Macromolecules

Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
HD Cas3-type domain-containing proteinC [auth A],
D [auth a]		81Vibrio phage ICP1_2004_AMutation(s): 0
Gene Names: TUST1-10_00455
UniProt
Find proteins for F1D5V9 (Vibrio phage ICP1_2004_A)
Explore F1D5V9
Go to UniProtKB:  F1D5V9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF1D5V9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:
(by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Cas1E [auth D],
F [auth d],
G [auth E],
H [auth e]		296Vibrio phage ICP1_2004_AMutation(s): 0
Gene Names: TUST1-10_00460
UniProt
Find proteins for F1D5W0 (Vibrio phage ICP1_2004_A)
Explore F1D5W0
Go to UniProtKB:  F1D5W0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF1D5W0
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
DNA (5'-D(P*CP*AP*AP*TP*TP*TP*AP*AP*AP*TP*AP*GP*GP*GP*AP*AP*G)-3')A [auth U]17Vibrio phage ICP1_2004_A
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(P*TP*TP*CP*CP*CP*TP*AP*TP*TP*TP*AP*AP*AP*TP*TP*GP*C)-3')B [auth V]17Vibrio phage ICP1_2004_A
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.40 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



View more in-depth experimental data
Entry History & Funding Information

Deposition Data

Funding OrganizationLocationGrant Number
National Science Foundation (NSF, China)China32171274

Revision History  (Full details and data files)

  • Version 1.0: 2024-07-17
    Type: Initial release
