8JJP

G protein-coupled receptor 1

• PDB DOI: https://doi.org/10.2210/pdb8JJP/pdb
• EM Map EMD-36364: EMDB EMDataResource

• Classification: MEMBRANE PROTEIN
• Organism(s): Homo sapiens, Mus musculus
• Expression System: Spodoptera frugiperda, Trichoplusia ni
• Mutation(s): No
• Membrane Protein: Yes  PDBTM


• Deposited: 2023-05-31 Released: 2024-08-21
• Deposition Author(s): Liu, A., Liu, Y., Chen, G., Ye, F.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 2.90 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

G protein-coupled receptor 1

Liu, A., Liu, Y., Chen, G., Ye, F.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 6-mer - A1B1C1D1E1F1

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 145.65 kDa
• Atom Count: 9,165
• Modelled Residue Count: 1,161
• Deposited Residue Count: 1,296
• Unique protein chains: 6

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Chemerin-like receptor 2	A	292	Homo sapiens	Mutation(s): 0  Gene Names: CMKLR2, GPR1 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P46091 (Homo sapiens) Explore P46091  Go to UniProtKB:  P46091
PHAROS:  P46091 GTEx:  ENSG00000183671

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(i) subunit alpha-1	B [auth C]	354	Homo sapiens	Mutation(s): 0  Gene Names: GNAI1 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P63096 (Homo sapiens) Explore P63096  Go to UniProtKB:  P63096
PHAROS:  P63096 GTEx:  ENSG00000127955

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1	C [auth B]	338	Homo sapiens	Mutation(s): 0  Gene Names: GNB1
UniProt & NIH Common Fund Data Resources
Find proteins for P62873 (Homo sapiens) Explore P62873  Go to UniProtKB:  P62873
PHAROS:  P62873 GTEx:  ENSG00000078369

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2	D [auth G]	56	Homo sapiens	Mutation(s): 0  Gene Names: GNG2 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P59768 (Homo sapiens) Explore P59768  Go to UniProtKB:  P59768
PHAROS:  P59768 GTEx:  ENSG00000186469

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
scFv16	E [auth S]	247	Mus musculus	Mutation(s): 0

Entity ID: 6
Molecule	Chains	Sequence Length	Organism	Details	Image
Retinoic acid receptor responder protein 2	F [auth L]	9	Homo sapiens	Mutation(s): 0  Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q99969 (Homo sapiens) Explore Q99969  Go to UniProtKB:  Q99969
PHAROS:  Q99969 GTEx:  ENSG00000106538

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
CLR	G [auth A]	CHOLESTEROL C27 H46 O HVYWMOMLDIMFJA-DPAQBDIFSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 2.90 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2024-08-21
Deposition Author(s): Liu, A., Liu, Y., Chen, G., Ye, F.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2024-08-21
  Type: Initial release
