8J6N | pdb_00008j6n

Crystal structure of Cystathionine gamma-lyase in complex with compound 1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:
    0.196 (Depositor), 0.204 (DCC)
  • R-Value Work:
    0.172 (Depositor), 0.182 (DCC)
  • R-Value Observed:
    0.174 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8J6N

Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history

Literature

Discovery of a cystathionine gamma-lyase (CSE) selective inhibitor targeting active-site pyridoxal 5'-phosphate (PLP) via Schiff base formation.

Echizen, H.Hanaoka, K.Shimamoto, K.Hibi, R.Toma-Fukai, S.Ohno, H.Sasaki, E.Komatsu, T.Ueno, T.Tsuchiya, Y.Watanabe, Y.Otsuka, T.Saito, H.Nagatoishi, S.Tsumoto, K.Kojima, H.Okabe, T.Shimizu, T.Urano, Y.

(2023) Sci Rep 13: 16456-16456

  • DOI: https://doi.org/10.1038/s41598-023-43536-6
  • Primary Citation Related Structures:
    8J6N

  • PubMed Abstract:

    D,L-Propargylglycine (PAG) has been widely used as a selective inhibitor to investigate the biological functions of cystathionine γ-lyase (CSE), which catalyzes the formation of reactive sulfur species (RSS). However, PAG also inhibits other PLP (pyridoxal-5'-phosphate)-dependent enzymes such as methionine γ-lyase (MGL) and L-alanine transaminase (ALT), so highly selective CSE inhibitors are still required. Here, we performed high-throughput screening (HTS) of a large chemical library and identified oxamic hydrazide 1 as a potent inhibitor of CSE (IC 50  = 13 ± 1 μM (mean ± S.E.)) with high selectivity over other PLP-dependent enzymes and RSS-generating enzymes. Inhibitor 1 inhibited the enzymatic activity of human CSE in living cells, indicating that it is sufficiently membrane-permeable. X-Ray crystal structure analysis of the complex of rat CSE (rCSE) with 1 revealed that 1 forms a Schiff base linkage with the cofactor PLP in the active site of rCSE. PLP in the active site may be a promising target for development of selective inhibitors of PLP-dependent enzymes, including RSS-generating enzymes such as cystathionine β-synthase (CBS) and cysteinyl-tRNA synthetase 2 (CARS2), which have unique substrate binding pocket structures.


  • Organizational Affiliation
    • Graduate School of Pharmaceutical Sciences, The University of Tokyo, 7-3-1 Hongo, Bunkyo-ku, Tokyo, 113-0033, Japan.

Macromolecule Content

  • Total Structure Weight: 520.65 kDa
  • Atom Count: 39,772
  • Modeled Residue Count: 4,679
  • Deposited Residue Count: 4,704
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Cystathionine gamma-lyase392Rattus norvegicusMutation(s): 0
Gene Names: CthCSE
EC: 4.4.1.1 (PDB Primary Data), 4.4.1.2 (UniProt)
UniProt
Find proteins for P18757 (Rattus norvegicus)
Explore P18757
Go to UniProtKB:  P18757
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP18757
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TVJ
(Subject of Investigation/LOI)

Query on TVJ



Download:Ideal Coordinates CCD File
DA [auth K]
GA [auth F]
IA [auth G]
JA [auth I]
LA [auth L]
DA [auth K],
GA [auth F],
IA [auth G],
JA [auth I],
LA [auth L],
M [auth A],
O [auth B],
Q [auth C],
S [auth D],
U [auth E],
W [auth H],
Y [auth J]
[6-methyl-4-[(~{E})-(oxamoylhydrazinylidene)methyl]-5-oxidanyl-pyridin-3-yl]methyl dihydrogen phosphate
C10 H13 N4 O7 P
QXOGMDGTZNDNSY-QLKAYGNNSA-N
GOL

Query on GOL



Download:Ideal Coordinates CCD File
EA [auth K]
HA [auth F]
KA [auth I]
MA [auth L]
N [auth A]
EA [auth K],
HA [auth F],
KA [auth I],
MA [auth L],
N [auth A],
P [auth B],
R [auth C],
T [auth D],
V [auth E],
X [auth H]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
EDO

Query on EDO



Download:Ideal Coordinates CCD File
AA [auth J],
BA [auth J],
CA [auth J],
FA [auth K],
Z [auth J]
1,2-ETHANEDIOL
C2 H6 O2
LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.90 Å
  • R-Value Free:  0.196 (Depositor), 0.204 (DCC)
  • R-Value Work:  0.172 (Depositor), 0.182 (DCC)
  • R-Value Observed: 0.174 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 176.214α = 90
b = 184.121β = 99.46
c = 175.944γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)Japan--

Revision History  (Full details and data files)

  • Version 1.0: 2024-02-14
    Type: Initial release
