8J12

Cryo-EM structure of the AsCas12f-sgRNA-target DNA ternary complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.08 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

An AsCas12f-based compact genome-editing tool derived by deep mutational scanning and structural analysis.

Hino, T.Omura, S.N.Nakagawa, R.Togashi, T.Takeda, S.N.Hiramoto, T.Tasaka, S.Hirano, H.Tokuyama, T.Uosaki, H.Ishiguro, S.Kagieva, M.Yamano, H.Ozaki, Y.Motooka, D.Mori, H.Kirita, Y.Kise, Y.Itoh, Y.Matoba, S.Aburatani, H.Yachie, N.Karvelis, T.Siksnys, V.Ohmori, T.Hoshino, A.Nureki, O.

(2023) Cell 186: 4920-4935.e23

  • DOI: https://doi.org/10.1016/j.cell.2023.08.031
  • Primary Citation of Related Structures:
    8J12, 8J1J, 8J3R

  • PubMed Abstract:

    SpCas9 and AsCas12a are widely utilized as genome-editing tools in human cells. However, their relatively large size poses a limitation for delivery by cargo-size-limited adeno-associated virus (AAV) vectors. The type V-F Cas12f from Acidibacillus sulfuroxidans is exceptionally compact (422 amino acids) and has been harnessed as a compact genome-editing tool. Here, we developed an approach, combining deep mutational scanning and structure-informed design, to successfully generate two AsCas12f activity-enhanced (enAsCas12f) variants. Remarkably, the enAsCas12f variants exhibited genome-editing activities in human cells comparable with those of SpCas9 and AsCas12a. The cryoelectron microscopy (cryo-EM) structures revealed that the mutations stabilize the dimer formation and reinforce interactions with nucleic acids to enhance their DNA cleavage activities. Moreover, enAsCas12f packaged with partner genes in an all-in-one AAV vector exhibited efficient knock-in/knock-out activities and transcriptional activation in mice. Taken together, enAsCas12f variants could offer a minimal genome-editing platform for in vivo gene therapy.


  • Organizational Affiliation

    Department of Cardiovascular Medicine, Graduate School of Medical Science, Kyoto Prefectural University of Medicine, Kyoto 602-8566, Japan.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Transposase IS605 OrfB C-terminal domain-containing protein
A, B
432Sulfoacidibacillus thermotoleransMutation(s): 0
Gene Names: BM613_13600
EC: 3.1
UniProt
Find proteins for A0A2U3D0N8 (Sulfoacidibacillus thermotolerans)
Explore A0A2U3D0N8
Go to UniProtKB:  A0A2U3D0N8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A2U3D0N8
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (38-MER)C [auth D]38Sulfoacidibacillus thermotolerans
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains LengthOrganismImage
DNA (38-MER)D [auth E]38Sulfoacidibacillus thermotolerans
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains LengthOrganismImage
RNA (247-MER)E [auth C]224Sulfoacidibacillus thermotolerans
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
G [auth A],
I [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
F [auth A]
H [auth B]
J [auth C]
K [auth C]
L [auth C]
F [auth A],
H [auth B],
J [auth C],
K [auth C],
L [auth C],
M [auth C],
N [auth C]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.08 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Agency for Medical Research and Development (AMED)Japan--

Revision History  (Full details and data files)

  • Version 1.0: 2023-09-27
    Type: Initial release
  • Version 1.1: 2024-10-09
    Changes: Data collection, Database references, Structure summary
