8I3W | pdb_00008i3w

BANAL-20-236 Spike trimer

PDB DOI: https://doi.org/10.2210/pdb8I3W/pdb
EM Map EMD-35160: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): unclassified Orthocoronavirinae
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2023-01-18 Released: 2024-01-24
Deposition Author(s): Wang, X., Xu, G.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.80 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8I3W

This is version 1.1 of the entry. See complete history.

Literature

The selective effect of fecal-oral transmission on the S proteins of bat SARS-CoV-2 related coronaviruses in favor of stability over infectivity

Wang, X., Xu, G.

To be published.

Macromolecule Content

Total Structure Weight: 440.74 kDa
Atom Count: 27,000
Modeled Residue Count: 3,345
Deposited Residue Count: 3,846
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,282	unclassified Orthocoronavirinae	Mutation(s): 0
UniProt
Find proteins for A0AAN0NP16 (unclassified Coronavirinae) Explore A0AAN0NP16 Go to UniProtKB: A0AAN0NP16
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0AAN0NP16
Glycosylation
Glycosylation Sites: 18	Glycosylation Focus chain A Focus chain B Focus chain C
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D, E, F, G, H D, E, F, G, H, I, J, K, L, M, N, O, P, Q, R	2		N-Glycosylation	Interactions Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H Focus chain I Focus chain J Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R Interactions & Density Focus chain D Focus chain E Focus chain F Focus chain G Focus chain H Focus chain I Focus chain J Focus chain K Focus chain L Focus chain M Focus chain N Focus chain O Focus chain P Focus chain Q Focus chain R
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain BA [auth A] SDF format, chain DA [auth A] SDF format, chain PA [auth B] SDF format, chain RA [auth B] SDF format, chain V [auth A] SDF format, chain VA [auth C] SDF format, chain ZA [auth C] SDF format, chain Z [auth A] SDF format, chain YA [auth C] SDF format, chain Y [auth A] SDF format, chain XA [auth C] SDF format, chain X [auth A] SDF format, chain WA [auth C] SDF format, chain W [auth A] SDF format, chain UA [auth C] SDF format, chain U [auth A] SDF format, chain TA [auth C] SDF format, chain T [auth A] SDF format, chain SA [auth C] SDF format, chain S [auth A] SDF format, chain QA [auth B] SDF format, chain OA [auth B] SDF format, chain NA [auth B] SDF format, chain MA [auth B] SDF format, chain LA [auth B] SDF format, chain KA [auth B] SDF format, chain JA [auth B] SDF format, chain IA [auth B] SDF format, chain HA [auth B] SDF format, chain GA [auth B] SDF format, chain FA [auth B] SDF format, chain EB [auth C] SDF format, chain EA [auth A] SDF format, chain DB [auth C] SDF format, chain CB [auth C] SDF format, chain CA [auth A] SDF format, chain BB [auth C] SDF format, chain AB [auth C] SDF format, chain AA [auth A] MOL2 format, chain BA [auth A] MOL2 format, chain DA [auth A] MOL2 format, chain PA [auth B] MOL2 format, chain RA [auth B] MOL2 format, chain V [auth A] MOL2 format, chain VA [auth C] MOL2 format, chain ZA [auth C] MOL2 format, chain Z [auth A] MOL2 format, chain YA [auth C] MOL2 format, chain Y [auth A] MOL2 format, chain XA [auth C] MOL2 format, chain X [auth A] MOL2 format, chain WA [auth C] MOL2 format, chain W [auth A] MOL2 format, chain UA [auth C] MOL2 format, chain U [auth A] MOL2 format, chain TA [auth C] MOL2 format, chain T [auth A] MOL2 format, chain SA [auth C] MOL2 format, chain S [auth A] MOL2 format, chain QA [auth B] MOL2 format, chain OA [auth B] MOL2 format, chain NA [auth B] MOL2 format, chain MA [auth B] MOL2 format, chain LA [auth B] MOL2 format, chain KA [auth B] MOL2 format, chain JA [auth B] MOL2 format, chain IA [auth B] MOL2 format, chain HA [auth B] MOL2 format, chain GA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain EB [auth C] MOL2 format, chain EA [auth A] MOL2 format, chain DB [auth C] MOL2 format, chain CB [auth C] MOL2 format, chain CA [auth A] MOL2 format, chain BB [auth C] MOL2 format, chain AB [auth C] MOL2 format, chain AA [auth A] mmCIF format, chain BA [auth A] mmCIF format, chain DA [auth A] mmCIF format, chain PA [auth B] mmCIF format, chain RA [auth B] mmCIF format, chain V [auth A] mmCIF format, chain VA [auth C] mmCIF format, chain ZA [auth C] mmCIF format, chain Z [auth A] mmCIF format, chain YA [auth C] mmCIF format, chain Y [auth A] mmCIF format, chain XA [auth C] mmCIF format, chain X [auth A] mmCIF format, chain WA [auth C] mmCIF format, chain W [auth A] mmCIF format, chain UA [auth C] mmCIF format, chain U [auth A] mmCIF format, chain TA [auth C] mmCIF format, chain T [auth A] mmCIF format, chain SA [auth C] mmCIF format, chain S [auth A] mmCIF format, chain QA [auth B] mmCIF format, chain OA [auth B] mmCIF format, chain NA [auth B] mmCIF format, chain MA [auth B] mmCIF format, chain LA [auth B] mmCIF format, chain KA [auth B] mmCIF format, chain JA [auth B] mmCIF format, chain IA [auth B] mmCIF format, chain HA [auth B] mmCIF format, chain GA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain EB [auth C] mmCIF format, chain EA [auth A] mmCIF format, chain DB [auth C] mmCIF format, chain CB [auth C] mmCIF format, chain CA [auth A] mmCIF format, chain BB [auth C] mmCIF format, chain AB [auth C] mmCIF format, chain AA [auth A]	AA [auth A] AB [auth C] BA [auth A] BB [auth C] CA [auth A] AA [auth A], AB [auth C], BA [auth A], BB [auth C], CA [auth A], CB [auth C], DA [auth A], DB [auth C], EA [auth A], EB [auth C], FA [auth B], GA [auth B], HA [auth B], IA [auth B], JA [auth B], KA [auth B], LA [auth B], MA [auth B], NA [auth B], OA [auth B], PA [auth B], QA [auth B], RA [auth B], S [auth A], SA [auth C], T [auth A], TA [auth C], U [auth A], UA [auth C], V [auth A], VA [auth C], W [auth A], WA [auth C], X [auth A], XA [auth C], Y [auth A], YA [auth C], Z [auth A], ZA [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth A] Focus chain AB [auth C] Focus chain BA [auth A] Focus chain BB [auth C] Focus chain CA [auth A] Focus chain CB [auth C] Focus chain DA [auth A] Focus chain DB [auth C] Focus chain EA [auth A] Focus chain EB [auth C] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth B] Focus chain NA [auth B] Focus chain OA [auth B] Focus chain PA [auth B] Focus chain QA [auth B] Focus chain RA [auth B] Focus chain S [auth A] Focus chain SA [auth C] Focus chain T [auth A] Focus chain TA [auth C] Focus chain U [auth A] Focus chain UA [auth C] Focus chain V [auth A] Focus chain VA [auth C] Focus chain W [auth A] Focus chain WA [auth C] Focus chain X [auth A] Focus chain XA [auth C] Focus chain Y [auth A] Focus chain YA [auth C] Focus chain Z [auth A] Focus chain ZA [auth C] Interactions & Density Focus chain AA [auth A] Focus chain AB [auth C] Focus chain BA [auth A] Focus chain BB [auth C] Focus chain CA [auth A] Focus chain CB [auth C] Focus chain DA [auth A] Focus chain DB [auth C] Focus chain EA [auth A] Focus chain EB [auth C] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain HA [auth B] Focus chain IA [auth B] Focus chain JA [auth B] Focus chain KA [auth B] Focus chain LA [auth B] Focus chain MA [auth B] Focus chain NA [auth B] Focus chain OA [auth B] Focus chain PA [auth B] Focus chain QA [auth B] Focus chain RA [auth B] Focus chain S [auth A] Focus chain SA [auth C] Focus chain T [auth A] Focus chain TA [auth C] Focus chain U [auth A] Focus chain UA [auth C] Focus chain V [auth A] Focus chain VA [auth C] Focus chain W [auth A] Focus chain WA [auth C] Focus chain X [auth A] Focus chain XA [auth C] Focus chain Y [auth A] Focus chain YA [auth C] Focus chain Z [auth A] Focus chain ZA [auth C]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.80 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-01-24

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2024-01-24
Type: Initial release
Version 1.1: 2024-11-20
Changes: Data collection, Structure summary
