8HD2

Crystal structure of SAM dependent methyltransferase encoded in type II fatty acid biosynthesis gene cluster from ladderane lipid producing anammox bacteria


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.180
  • R-Value Observed: 0.181

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Anammox Bacterial S -Adenosyl-l-Methionine Dependent Methyltransferase Crystal Structure and Its Interaction with Acyl Carrier Proteins.

Uegaki, T.Takei, T.Yamaguchi, S.Fujiyama, K.Sato, Y.Hino, T.Nagano, S.

(2023) Int J Mol Sci 24

  • DOI: https://doi.org/10.3390/ijms24010744
  • Primary Citation of Related Structures:
    8HD2

  • PubMed Abstract:

    Ladderane lipids (found in the membranes of anaerobic ammonium-oxidizing [anammox] bacteria) have unique ladder-like hydrophobic groups, and their highly strained exotic structure has attracted the attention of scientists. Although enzymes encoded in type II fatty acid biosynthesis (FASII) gene clusters in anammox bacteria, such as S -adenosyl-l-methionine (SAM)-dependent enzymes, have been proposed to construct a ladder-like structure using a substrate connected to acyl carrier protein from anammox bacteria (AmxACP), no experimental evidence to support this hypothesis was reported to date. Here, we report the crystal structure of a SAM-dependent methyltransferase from anammox bacteria (AmxMT1) that has a substrate and active site pocket between a class I SAM methyltransferase-like core domain and an additional α-helix inserted into the core domain. Structural comparisons with homologous SAM-dependent C -methyltransferases in polyketide synthase, AmxACP pull-down assays, AmxACP/AmxMT1 complex structure predictions by AlphaFold, and a substrate docking simulation suggested that a small compound connected to AmxACP could be inserted into the pocket of AmxMT1, and then the enzyme transfers a methyl group from SAM to the substrate to produce branched lipids. Although the enzymes responsible for constructing the ladder-like structure remain unknown, our study, for the first time, supports the hypothesis that biosynthetic intermediates connected to AmxACP are processed by SAM-dependent enzymes, which are not typically involved in the FASII system, to produce the ladder-like structure of ladderane lipids in anammox bacteria.


  • Organizational Affiliation

    Department of Chemistry, Graduate School of Engineering, Tottori University, 4-101 Koyama-cho Minami, Tottori 680-8552, Japan.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Methyltransf_25 domain-containing protein354Candidatus Brocadia fulgidaMutation(s): 0
Gene Names: KKO18993.1
UniProt
Find proteins for A0A0M2USF2 (Candidatus Brocadia fulgida)
Explore A0A0M2USF2
Go to UniProtKB:  A0A0M2USF2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A0M2USF2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SAH (Subject of Investigation/LOI)
Query on SAH

Download Ideal Coordinates CCD File
B [auth A]S-ADENOSYL-L-HOMOCYSTEINE
C14 H20 N6 O5 S
ZJUKTBDSGOFHSH-WFMPWKQPSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.60 Å
  • R-Value Free: 0.208
  • R-Value Work: 0.180
  • R-Value Observed: 0.181
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 35.016α = 82.59
b = 48.06β = 84.12
c = 49.828γ = 70.67
Software Package:
Software NamePurpose
PHENIXrefinement
DIALSdata reduction
pointlessdata scaling
AutoSolphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Society for the Promotion of Science (JSPS)Japan17H05444
Japan Society for the Promotion of Science (JSPS)Japan19H04658

Revision History  (Full details and data files)

  • Version 1.0: 2023-05-17
    Type: Initial release
  • Version 1.1: 2024-05-29
    Changes: Data collection
