8GOH | pdb_00008goh

Homotetramic Antiparallel Coiled-Coil of 23-residues LacI C-terminal tetramerization helix

PDB DOI: https://doi.org/10.2210/pdb8GOH/pdb

Classification: DNA BINDING PROTEIN
Organism(s): Escherichia coli
Mutation(s): No

Deposited: 2022-08-25 Released: 2023-08-30
Deposition Author(s): Kumasaka, T.
Funding Organization(s): Japan Science and Technology

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.10 Å
R-Value Free:
0.228 (Depositor), 0.228 (DCC)
R-Value Work:
0.207 (Depositor), 0.207 (DCC)
R-Value Observed:
0.208 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8GOH

This is version 1.1 of the entry. See complete history.

Literature

Design of interchain Glu-Arg salt-bridges stabilizing heterotetrameric coiled-coil derived from Lac repressor.

Otsuka, Y., Osaki, A., Nakamura, Y., Mizuno, N., Kawamura, T., Hasegawa, K., Yamaguchi, H., Kumasaka, T.

To be published.

Macromolecule Content

Total Structure Weight: 20.7 kDa
Atom Count: 1,489
Modeled Residue Count: 174
Deposited Residue Count: 184
Unique protein chains: 1

Macromolecules

Find similar proteins by: Sequence | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
LacI C-terminal tetramerization helix	A, B, C, D, E A, B, C, D, E, F, G, H	23	Escherichia coli	Mutation(s): 0
UniProt
Find proteins for P03023 (Escherichia coli (strain K12)) Explore P03023 Go to UniProtKB: P03023
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P03023
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
1PE Query on 1PE Download:Ideal Coordinates CCD File SDF format, chain L [auth H] SDF format, chain K [auth E] SDF format, chain J [auth B] SDF format, chain I [auth A] MOL2 format, chain L [auth H] MOL2 format, chain K [auth E] MOL2 format, chain J [auth B] MOL2 format, chain I [auth A] mmCIF format, chain L [auth H] mmCIF format, chain K [auth E] mmCIF format, chain J [auth B] mmCIF format, chain I [auth A]	I [auth A], J [auth B], K [auth E], L [auth H]	PENTAETHYLENE GLYCOL C₁₀ H₂₂ O₆ JLFNLZLINWHATN-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth E] Focus chain L [auth H] Interactions & Density Focus chain I [auth A] Focus chain J [auth B] Focus chain K [auth E] Focus chain L [auth H]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.10 Å
R-Value Free: 0.228 (Depositor), 0.228 (DCC)
R-Value Work: 0.207 (Depositor), 0.207 (DCC)
R-Value Observed: 0.208 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.257	α = 90
b = 50.935	β = 113.84
c = 40.849	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-08-30

Deposition Author(s):

Funding Organization	Location	Grant Number
Japan Science and Technology	Japan	JPMJAC1304

Revision History (Full details and data files)

Version 1.0: 2023-08-30
Type: Initial release
Version 1.1: 2026-03-04
Changes: Refinement description, Structure summary
