8F6X | pdb_00008f6x

cryo-EM structure of a structurally designed Human metapneumovirus F protein in complex with antibody MPE8

PDB DOI: https://doi.org/10.2210/pdb8F6X/pdb
EM Map EMD-28891: EMDB EMDataResource

Classification: VIRAL PROTEIN/IMMUNE SYSTEM
Organism(s): human metapneumovirus, Escherichia phage T2, Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2022-11-17 Released: 2023-08-02
Deposition Author(s): Zhou, T., Kwong, P.D., Morano, N.C., Ou, L.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.25 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8F6X

This is version 1.2 of the entry. See complete history.

Literature

cryo-EM structure of a structurally designed Human metapneumovirus F protein in complex with antibody MPE8

Ou, L., Kwong, P.D.

To be published.

Macromolecule Content

Total Structure Weight: 267.37 kDa
Atom Count: 14,952
Modeled Residue Count: 1,980
Deposited Residue Count: 2,484
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Structurally designed HMPV F protein HMPV_v3B_D12_DS454,Fibritin	A, B, C	522	human metapneumovirus, Escherichia phage T2	Mutation(s): 7
UniProt
Find proteins for G3KCK8 (human metapneumovirus) Explore G3KCK8 Go to UniProtKB: G3KCK8
Find proteins for P10104 (Enterobacteria phage T4) Explore P10104 Go to UniProtKB: P10104
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Groups	G3KCK8 P10104
Glycosylation
Glycosylation Sites: 1	Glycosylation Focus chain A Focus chain B Focus chain C
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
MPE8 Single chain variable fragment	D, E, F	306	Homo sapiens	Mutation(s): 0

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain I [auth C] SDF format, chain H [auth B] MOL2 format, chain G [auth A] MOL2 format, chain I [auth C] MOL2 format, chain H [auth B] mmCIF format, chain G [auth A] mmCIF format, chain I [auth C] mmCIF format, chain H [auth B]	G [auth A], H [auth B], I [auth C]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain G [auth A] Focus chain H [auth B] Focus chain I [auth C] Interactions & Density Focus chain G [auth A] Focus chain H [auth B] Focus chain I [auth C]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.25 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-08-02

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History (Full details and data files)

Version 1.0: 2023-08-02
Type: Initial release
Version 1.1: 2024-10-23
Changes: Data collection, Structure summary
Version 1.2: 2025-05-21
Changes: Data collection
