8F2J | pdb_00008f2j

Crystal structure of antibody WRAIR-2134 in complex with SARS-CoV-2 receptor binding domain

• PDB DOI: https://doi.org/10.2210/pdb8F2J/pdb

• Classification: VIRAL PROTEIN/IMMUNE SYSTEM
• Organism(s): Homo sapiens, Severe acute respiratory syndrome coronavirus 2
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2022-11-08 Released: 2023-12-13
• Deposition Author(s): Sankhala, R.S., Joyce, M.G.
• Funding Organization(s): Department of Defense (DOD, United States)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 3.16 Å
• R-Value Free:
  0.245 (Depositor), 0.250 (DCC)
• R-Value Work:
  0.209 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.211 (Depositor)

Literature

Antibody Targeting of Conserved Sites of Vulnerability on the SARS-CoV-2 Spike Receptor-Binding Domain.

Sankhala, R.S., Dussupt, V., Jensen, J., Modjarrad, K., Joyce, M.G.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 3-mer - A2B1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 2 assigned by authors.

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 3-mer - A2B1

Biological assembly 3 assigned by authors.

Biological Assembly 4

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 4 assigned by authors.

Macromolecule Content

• Total Structure Weight: 285.57 kDa
• Atom Count: 19,674
• Modeled Residue Count: 2,556
• Deposited Residue Count: 2,608
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
WRAIR-2134 Fab Heavy Chain	A, C [auth D], E [auth H], F [auth I]	233	Homo sapiens	Mutation(s): 0

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
WRAIR-2134 Fab Light Chain	B, D [auth F], G [auth J], H [auth L]	214	Homo sapiens	Mutation(s): 0

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike protein S1	I [auth C], J [auth E], K [auth G], L [auth K]	205	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2  Go to UniProtKB:  P0DTC2
Glycosylation
Glycosylation Sites: 1		Go to GlyGen: P0DTC2-1

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	M, N	2		N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT GlyCosmos:  G42666HT GlyGen:  G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NAG	O [auth C], P [auth E]	2-acetamido-2-deoxy-beta-D-glucopyranose C8 H15 N O6 OVRNDRQMDRJTHS-FMDGEEDCSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 3.16 Å
• R-Value Free:  0.245 (Depositor), 0.250 (DCC)
• R-Value Work:  0.209 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.211 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 143.19	α = 90
b = 154.43	β = 90
c = 165.25	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-12-13
Deposition Author(s): Sankhala, R.S., Joyce, M.G.

---

Funding Organization	Location	Grant Number
Department of Defense (DOD, United States)	United States	W81XWH-18-2-0040

Revision History

• Version 1.0: 2023-12-13
  Type: Initial release

• Version 1.1: 2024-10-30
  Changes: Structure summary
