8CXH

Structures of Zika Virus in Complex with Antibodies Targeting E Dimer Epitopes and Basis for Neutralization Efficacy

• PDB DOI: https://doi.org/10.2210/pdb8CXH/pdb
• EM Map EMD-27056: EMDB EMDataResource

• Classification: VIRUS/IMMUNE SYSTEM
• Organism(s): Zika virus, Homo sapiens
• Expression System: Homo sapiens
• Mutation(s): No


• Deposited: 2022-05-21 Released: 2023-06-07
• Deposition Author(s): Liu, W., Zhang, X.K., Gong, D.Y., Dai, X.H., Sharma, A., Zhang, T.H., Rey, F., Zhou, Z.H.
• Funding Organization(s): National Institutes of Health/National Institute of Dental and Craniofacial Research (NIH/NIDCR), National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Science Foundation (NSF, United States)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.20 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

Structures of Zika Virus in Complex with Antibodies Targeting E Dimer Epitopes and Basis for Neutralization Efficacy

Liu, W., Zhang, X.K., Gong, D.Y., Dai, X.H., Sharma, A., Zhang, T.H., Rey, F., Zhou, Z.H.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 10-mer - A3B3C2D2 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 10-mer - A4B3C3 Local Symmetry: Cyclic - C2  (Explore in 3D)
Local Stoichiometry: Hetero 4-mer - A2B2

Local Symmetry: Cyclic - C2  (Explore in 3D)
Local Stoichiometry: Hetero 4-mer - A2B2

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: microscopy

Macromolecule Content

• Total Structure Weight: 1,398.78 kDa
• Atom Count: 16,634
• Modelled Residue Count: 2,178
• Deposited Residue Count: 12,662
• Unique protein chains: 4

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Ankyrin repeat family A protein 2,Envelope E protein	A, E [auth B], I [auth C]	639	Zika virus	Mutation(s): 0  Gene Names: ANKRA2, ANKRA
UniProt & NIH Common Fund Data Resources
Find proteins for A0A142DS37 (Zika virus) Explore A0A142DS37  Go to UniProtKB:  A0A142DS37
Find proteins for Q9H9E1 (Homo sapiens) Explore Q9H9E1  Go to UniProtKB:  Q9H9E1
PHAROS:  Q9H9E1 GTEx:  ENSG00000164331
UniProt Groups	A0A142DS37Q9H9E1

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Membrane M protein	B [auth D], F [auth E], J [auth F]	3,423	Zika virus	Mutation(s): 0
UniProt
Find proteins for A0A1S6LXE0 (Zika virus) Explore A0A1S6LXE0  Go to UniProtKB:  A0A1S6LXE0

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
C10 heavy chain	C [auth H], G [auth h]	128	Homo sapiens	Mutation(s): 0

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
C10 light chain	D [auth L], H [auth l]	110	Homo sapiens	Mutation(s): 0

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.20 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-06-07
Deposition Author(s): Liu, W., Zhang, X.K., Gong, D.Y., Dai, X.H., Sharma, A., Zhang, T.H., Rey, F., Zhou, Z.H.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of Dental and Craniofacial Research (NIH/NIDCR)	United States	DE028583, DE025567
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	1S10RR23057, 1S10OD018111, and 1U24GM116792
National Science Foundation (NSF, United States)	United States	DBI-1338135 and DMR-1548924

Revision History

• Version 1.0: 2023-06-07
  Type: Initial release

• Version 1.1: 2024-11-06
  Changes: Data collection, Structure summary
