8CRO

Cryo-EM structure of Pyrococcus furiosus transcription elongation complex


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history

Re-refinement Note

A newer entry is available that reflects an alternative modeling of the original data: 8OKI


Literature

Structural basis of archaeal RNA polymerase transcription elongation and Spt4/5 recruitment.

Tarau, D.Grunberger, F.Pilsl, M.Reichelt, R.Heiss, F.Konig, S.Urlaub, H.Hausner, W.Engel, C.Grohmann, D.

(2024) Nucleic Acids Res 52: 6017-6035

  • DOI: https://doi.org/10.1093/nar/gkae282
  • Primary Citation of Related Structures:
    8CRO, 8OKI, 8ORQ, 8P2I, 8RBO

  • PubMed Abstract:

    Archaeal transcription is carried out by a multi-subunit RNA polymerase (RNAP) that is highly homologous in structure and function to eukaryotic RNAP II. Among the set of basal transcription factors, only Spt5 is found in all domains of life, but Spt5 has been shaped during evolution, which is also reflected in the heterodimerization of Spt5 with Spt4 in Archaea and Eukaryotes. To unravel the mechanistic basis of Spt4/5 function in Archaea, we performed structure-function analyses using the archaeal transcriptional machinery of Pyrococcus furiosus (Pfu). We report single-particle cryo-electron microscopy reconstructions of apo RNAP and the archaeal elongation complex (EC) in the absence and presence of Spt4/5. Surprisingly, Pfu Spt4/5 also binds the RNAP in the absence of nucleic acids in a distinct super-contracted conformation. We show that the RNAP clamp/stalk module exhibits conformational flexibility in the apo state of RNAP and that the enzyme contracts upon EC formation or Spt4/5 engagement. We furthermore identified a contact of the Spt5-NGN domain with the DNA duplex that stabilizes the upstream boundary of the transcription bubble and impacts Spt4/5 activity in vitro. This study, therefore, provides the structural basis for Spt4/5 function in archaeal transcription and reveals a potential role beyond the well-described support of elongation.


  • Organizational Affiliation

    Institute of Microbiology & Archaea Centre, Single-Molecule Biochemistry Lab, University of Regensburg, 93053 Regensburg, Germany.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo1N910Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpoA1rpo1NPFDSM3638_07875
EC: 2.7.7.6
UniProt
Find proteins for Q8U0M4 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U0M4
Go to UniProtKB:  Q8U0M4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U0M4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit beta1,117Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: PF1564
UniProt
Find proteins for Q8U0M3 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U0M3
Go to UniProtKB:  Q8U0M3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U0M3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo1C397Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo1CrpoA2PF1562
EC: 2.7.7.6
UniProt
Find proteins for Q8U0M5 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U0M5
Go to UniProtKB:  Q8U0M5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U0M5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo3261Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo3rpoDPF1647
EC: 2.7.7.6
UniProt
Find proteins for Q8U0E4 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U0E4
Go to UniProtKB:  Q8U0E4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U0E4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo7189Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo7
UniProt
Find proteins for Q8U439 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U439
Go to UniProtKB:  Q8U439
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U439
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo4120Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo4rpoFPF1036
EC: 2.7.7.6
UniProt
Find proteins for Q8U216 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U216
Go to UniProtKB:  Q8U216
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U216
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo11G [auth L]95Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo11rpoLPF0050
EC: 2.7.7.6
UniProt
Find proteins for Q8U4N1 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U4N1
Go to UniProtKB:  Q8U4N1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U4N1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo582Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo5rpoHPF1565
EC: 2.7.7.6
UniProt
Find proteins for Q8U0M2 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U0M2
Go to UniProtKB:  Q8U0M2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U0M2
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo10I [auth N]65Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo10rpoNPF1643
EC: 2.7.7.6
UniProt
Find proteins for P60292 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore P60292
Go to UniProtKB:  P60292
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP60292
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo6J [auth K]57Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo6rpoKPF1642
EC: 2.7.7.6
UniProt
Find proteins for Q8U0E8 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8U0E8
Go to UniProtKB:  Q8U0E8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8U0E8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-directed RNA polymerase subunit Rpo12K [auth P]49Pyrococcus furiosus DSM 3638Mutation(s): 0
Gene Names: rpo12rpoPPF2009
EC: 2.7.7.6
UniProt
Find proteins for Q8TZI3 (Pyrococcus furiosus (strain ATCC 43587 / DSM 3638 / JCM 8422 / Vc1))
Explore Q8TZI3
Go to UniProtKB:  Q8TZI3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8TZI3
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 12
MoleculeChains LengthOrganismImage
DNA Template StrandL [auth X]20Pyrococcus furiosus DSM 3638
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 13
MoleculeChains LengthOrganismImage
DNA Non-Template StrandM [auth Y]10Pyrococcus furiosus DSM 3638
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 14
MoleculeChains LengthOrganismImage
RNAN [auth Z]9Pyrococcus furiosus DSM 3638
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.10 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION
MODEL REFINEMENTPHENIX1.20.1-4487

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
German Research Foundation (DFG)GermanySFB960

Revision History  (Full details and data files)

  • Version 1.0: 2024-04-17
    Type: Initial release
  • Version 1.1: 2024-05-15
    Changes: Database references
  • Version 1.2: 2024-06-19
    Changes: Database references
