8CLA | pdb_00008cla

Z-SBTubA4 photoswitch bound to tubulin-DARPin D1 complex

PDB DOI: https://doi.org/10.2210/pdb8CLA/pdb

Classification: CELL CYCLE
Organism(s): Bos taurus, synthetic construct
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2023-02-16 Released: 2024-02-28
Deposition Author(s): Wranik, M., Bertrand, Q., Kepa, M.W., Weinert, T., Steinmetz, M., Standfuss, J.
Funding Organization(s): Swiss National Science Foundation

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.206 (Depositor), 0.204 (DCC)
R-Value Work:
0.155 (Depositor), 0.174 (DCC)
R-Value Observed:
0.156 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

A multi-reservoir extruder for time-resolved serial protein crystallography and compound screening at X-ray free electron lasers

Wranik, M., Kepa, M.W., Beale, E.V., James, D., Bertrand, Q., Weinert, T., Furrer, A., Glover, H., Gashi, D., Carrillo, M., Kondo, Y., Stipp, R.T., Khusainov, G., Nass, K., Ozerov, D., Cirelli, C., Johnson, P.J.M., Dworkowski, F., Beale, J.H., Stubbs, S., Schneider, M., Krauskopf, K., Gao, L., Thorn-Seshold, O., Bostedt, C., Bacellar, C., Steinmetz, M.O., Milne, C., Standfuss, J.

To be published.

Macromolecule Content

Total Structure Weight: 114.51 kDa
Atom Count: 8,413
Modeled Residue Count: 1,020
Deposited Residue Count: 1,020
Unique protein chains: 3

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Tubulin alpha-1B chain	A	435	Bos taurus	Mutation(s): 0 EC: 3.6.5
UniProt
Find proteins for P81947 (Bos taurus) Explore P81947 Go to UniProtKB: P81947
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P81947
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Tubulin beta-2B chain	B	430	Bos taurus	Mutation(s): 0
UniProt
Find proteins for Q6B856 (Bos taurus) Explore Q6B856 Go to UniProtKB: Q6B856
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q6B856
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

| 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Designed Ankyrin Repeat Protein (DARPIN) D1	C [auth F]	155	synthetic construct	Mutation(s): 0

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GTP Query on GTP Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	GUANOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₄ P₃ XKMLYUALXHKNFT-UUOKFMHZSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
GDP Query on GDP Download:Ideal Coordinates CCD File SDF format, chain G [auth B] MOL2 format, chain G [auth B] mmCIF format, chain G [auth B]	G [auth B]	GUANOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₁ P₂ QGWNDRXFNXRZMB-UUOKFMHZSA-N		Interactions Focus chain G [auth B] Interactions & Density Focus chain G [auth B]
I8R (Subject of Investigation/LOI) Query on I8R Download:Ideal Coordinates CCD File SDF format, chain H [auth B] MOL2 format, chain H [auth B] mmCIF format, chain H [auth B]	H [auth B]	2-methoxy-5-[2-(5,6,7-trimethoxy-1,3-benzothiazol-2-yl)ethyl]phenol C₁₉ H₂₁ N O₅ S AGSIMEHHCHGERU-UHFFFAOYSA-N		Interactions Focus chain H [auth B] Interactions & Density Focus chain H [auth B]
CA Query on CA Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.206 (Depositor), 0.204 (DCC)
R-Value Work: 0.155 (Depositor), 0.174 (DCC)
R-Value Observed: 0.156 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 73.23	α = 90
b = 90.94	β = 96.74
c = 82.43	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
CrystFEL	data reduction
CrystFEL	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-02-28

Deposition Author(s):

Funding Organization	Location	Grant Number
Swiss National Science Foundation	Switzerland	31003A_179351
Swiss National Science Foundation	Switzerland	310030_207462
Swiss National Science Foundation	Switzerland	310030_192566
