8CGJ

Streptomycin bound to the 30S body


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 1.79 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Structural conservation of antibiotic interaction with ribosomes.

Paternoga, H.Crowe-McAuliffe, C.Bock, L.V.Koller, T.O.Morici, M.Beckert, B.Myasnikov, A.G.Grubmuller, H.Novacek, J.Wilson, D.N.

(2023) Nat Struct Mol Biol 30: 1380-1392

  • DOI: https://doi.org/10.1038/s41594-023-01047-y
  • Primary Citation of Related Structures:
    8CA7, 8CAI, 8CAM, 8CAZ, 8CEP, 8CEU, 8CF1, 8CF8, 8CGD, 8CGI, 8CGJ, 8CGK, 8CGR, 8CGU, 8CGV

  • PubMed Abstract:

    The ribosome is a major target for clinically used antibiotics, but multidrug resistant pathogenic bacteria are making our current arsenal of antimicrobials obsolete. Here we present cryo-electron-microscopy structures of 17 distinct compounds from six different antibiotic classes bound to the bacterial ribosome at resolutions ranging from 1.6 to 2.2 Å. The improved resolution enables a precise description of antibiotic-ribosome interactions, encompassing solvent networks that mediate multiple additional interactions between the drugs and their target. Our results reveal a high structural conservation in the binding mode between antibiotics with the same scaffold, including ordered water molecules. Water molecules are visualized within the antibiotic binding sites that are preordered, become ordered in the presence of the drug and that are physically displaced on drug binding. Insight into RNA-ligand interactions will facilitate development of new antimicrobial agents, as well as other RNA-targeting therapies.


  • Organizational Affiliation

    Institute for Biochemistry and Molecular Biology, University of Hamburg, Hamburg, Germany.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S2241Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7V0 (Escherichia coli (strain K12))
Explore P0A7V0
Go to UniProtKB:  P0A7V0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS3233Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7V3 (Escherichia coli (strain K12))
Explore P0A7V3
Go to UniProtKB:  P0A7V3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS4206Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7V8 (Escherichia coli (strain K12))
Explore P0A7V8
Go to UniProtKB:  P0A7V8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7V8
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS5167Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7W1 (Escherichia coli (strain K12))
Explore P0A7W1
Go to UniProtKB:  P0A7W1
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7W1
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein bS6, non-modified isoform131Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P02358 (Escherichia coli (strain K12))
Explore P02358
Go to UniProtKB:  P02358
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP02358
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS8G [auth H]130Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7W7 (Escherichia coli (strain K12))
Explore P0A7W7
Go to UniProtKB:  P0A7W7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7W7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS11H [auth K]129Escherichia coli BW25113Mutation(s): 1
UniProt
Find proteins for P0A7R9 (Escherichia coli (strain K12))
Explore P0A7R9
Go to UniProtKB:  P0A7R9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7R9
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS12I [auth L]124Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7S3 (Escherichia coli (strain K12))
Explore P0A7S3
Go to UniProtKB:  P0A7S3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7S3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS15J [auth O]89Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0ADZ4 (Escherichia coli (strain K12))
Explore P0ADZ4
Go to UniProtKB:  P0ADZ4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0ADZ4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S16K [auth P]82Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7T3 (Escherichia coli (strain K12))
Explore P0A7T3
Go to UniProtKB:  P0A7T3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7T3
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein uS17L [auth Q]84Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0AG63 (Escherichia coli (strain K12))
Explore P0AG63
Go to UniProtKB:  P0AG63
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AG63
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein bS18M [auth R]75Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7T7 (Escherichia coli (strain K12))
Explore P0A7T7
Go to UniProtKB:  P0A7T7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7T7
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains Sequence LengthOrganismDetailsImage
Small ribosomal subunit protein bS21N [auth U]71Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P68679 (Escherichia coli (strain K12))
Explore P68679
Go to UniProtKB:  P68679
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP68679
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
30S ribosomal protein S20O [auth T]87Escherichia coli BW25113Mutation(s): 0
UniProt
Find proteins for P0A7U7 (Escherichia coli (strain K12))
Explore P0A7U7
Go to UniProtKB:  P0A7U7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0A7U7
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains LengthOrganismImage
16S rRNA1,540Escherichia coli BW25113
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChains LengthOrganismImage
23S rRNAP [auth a]2,904Escherichia coli BW25113
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
5I0 (Subject of Investigation/LOI)
Query on 5I0

Download Ideal Coordinates CCD File
S [auth A][(2~{S},3~{S},4~{S},5~{R},6~{S})-2-[(2~{R},3~{R},4~{R},5~{S})-2-[(1~{R},2~{S},3~{R},4~{R},5~{S},6~{R})-2,4-bis[[azaniumylidene(azanyl)methyl]amino]-3,5,6-tris(oxidanyl)cyclohexyl]oxy-4-[bis(oxidanyl)methyl]-5-methyl-4-oxidanyl-oxolan-3-yl]oxy-6-(hydroxymethyl)-4,5-bis(oxidanyl)oxan-3-yl]-methyl-azanium
C21 H44 N7 O13
ATLHDHNZEMANQF-UQHZJGBMSA-Q
TAC (Subject of Investigation/LOI)
Query on TAC

Download Ideal Coordinates CCD File
T [auth A]TETRACYCLINE
C22 H24 N2 O8
OFVLGDICTFRJMM-WESIUVDSSA-N
K
Query on K

Download Ideal Coordinates CCD File
BD [auth F]
CC [auth A]
DC [auth A]
EC [auth A]
FC [auth A]
BD [auth F],
CC [auth A],
DC [auth A],
EC [auth A],
FC [auth A],
GC [auth A],
HC [auth A],
IC [auth A],
JC [auth A],
KC [auth A],
LC [auth A],
MC [auth A],
NC [auth A],
OC [auth A],
PC [auth A],
Q [auth A],
QC [auth A],
R [auth A],
RC [auth A],
SC [auth A],
TC [auth A],
UC [auth A],
VC [auth A],
WC [auth A],
XC [auth A]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
AA [auth A]
AB [auth A]
AC [auth A]
AD [auth A]
BA [auth A]
AA [auth A],
AB [auth A],
AC [auth A],
AD [auth A],
BA [auth A],
BB [auth A],
BC [auth A],
CA [auth A],
CB [auth A],
DA [auth A],
DB [auth A],
EA [auth A],
EB [auth A],
FA [auth A],
FB [auth A],
GA [auth A],
GB [auth A],
HA [auth A],
HB [auth A],
IA [auth A],
IB [auth A],
JA [auth A],
JB [auth A],
KA [auth A],
KB [auth A],
LA [auth A],
LB [auth A],
MA [auth A],
MB [auth A],
NA [auth A],
NB [auth A],
OA [auth A],
OB [auth A],
PA [auth A],
PB [auth A],
QA [auth A],
QB [auth A],
RA [auth A],
RB [auth A],
SA [auth A],
SB [auth A],
TA [auth A],
TB [auth A],
U [auth A],
UA [auth A],
UB [auth A],
V [auth A],
VA [auth A],
VB [auth A],
W [auth A],
WA [auth A],
WB [auth A],
X [auth A],
XA [auth A],
XB [auth A],
Y [auth A],
YA [auth A],
YB [auth A],
YC [auth A],
Z [auth A],
ZA [auth A],
ZB [auth A],
ZC [auth A]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
D2T
Query on D2T
I [auth L]L-PEPTIDE LINKINGC5 H9 N O4 SASP
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 1.79 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTREFMAC5.8.0415

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Other governmentDLR01Kl1820
iNEXT-DiscoveryEuropean Union871037
Other governmentLM2018127

Revision History  (Full details and data files)

  • Version 1.0: 2023-07-26
    Type: Initial release
  • Version 1.1: 2023-08-09
    Changes: Database references
  • Version 1.2: 2023-08-16
    Changes: Data collection, Database references
  • Version 1.3: 2023-09-20
    Changes: Database references
  • Version 1.4: 2023-11-15
    Changes: Data collection, Derived calculations
  • Version 1.5: 2024-04-24
    Changes: Data collection
